Parameter
Transmitter Peak Wave
Length
Spectral Width
Rise Time
Fall Time
Duty Cycle
Bit Error Rate
The transmitter power levels given above are Peak Power Levels after optical
overshoot. You must use a Peak Power Meter to correctly compare the values
NOTE
given above to those measured on any particular port. If you are measuring
power levels with an Average Power Meter, add 3 dBm to the average power
measurement to correctly compare the average power values measured to the
values listed above (i.e., -33.5 dBm average + 3 dB = -30.5 dBm peak).
Table A-3. EPIM-F3 Specifications
Typical
1300 nm
60 nm
3.0 nsec
2.5 nsec
50.1%
Better than 10
Minimum Maximum
1270 nm 1330 nm
- 100 nm
2.7 nsec 5.0 nsec
2.2 nsec 5.0 nsec
49.6% 50.7%
-10
