F R E Y 6 0 " V A N I T Y
WITH SEMI-RECESSED SINK
SKU:949568, 949569, 949572
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
vanity, plumbing, countertop, sink, or for personal injury
during installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
For Warranty information, please visit: signaturehardware.com/services/warranty
TOOLS AND MATERIALS:
Silicone Sealant
(100% Neutral Cure)
HARDWARE LIST
Screw
M6x20 - 20pcs
1
Damp Cloth
Washer
Allen wrench
19x2 - 16pcs
4mm - 1pc
REVISED 01/28/2021
CODES: 531239, 531240, 531241
Advertisement
Related Manuals for Signature Hardware FREY 949568
Summary of Contents for Signature Hardware FREY 949568
- Page 1 F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 TOOLS AND MATERIALS: BEFORE YOU BEGIN We recommend consulting a professional if you are unfamiliar with installing plumbing �xtures. Signature Hardware accepts no liability for any damage to the vanity, plumbing, countertop, sink, or for personal injury Damp Cloth Silicone Sealant...
-
Page 2: Installation
F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 INSTALLATION 1. Turn vanity cabinet upside down on soft surface. Align mounting holes in feet with mounting points on vanity cabinet. - Page 3 F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 2. Using provided allen wrench (C) fasten feet to vanity cabinet with washer (B) and screw (A) as shown.
-
Page 4: Countertop Installation
F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 COUNTERTOP INSTALLATION 1. Apply a bead of silicone sealant around the top edge 3. If you are installing a side-splash and/or back-splash, of the vanity cabinet. - Page 5 F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 SINK INSTALLATION 5. For stone tops, such as marble and granite, it is 1. Carefully place your semi-recessed sink upside recommended that you apply a high-quality sealer to down on the countertop.
- Page 6 F R E Y 6 0 ” V A N I T Y WITH SEMI-RECESSED SINK SKU:949568, 949569, 949572 5. Let the assembled vanity sit for 24 hours to allow all 3. Turn the sink back over, placing it inside the sink’s cutout and adjust the sink as necessary until centered.
