BATTISTA CABINET DOOR HARDWARE INSTALLATION
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing this type of hardware. Signature
Hardware accepts no liability for any damage to the
hardware, door, cabinet, walls, floor, or for personal injury
during installation.
Observe all local building codes.
Unpack and inspect the items for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
GETTING STARTED GETTING STARTED
Ensure that you have gathered all the required Ensure that you have gathered all the required
materials that are needed for the installation. materials that are needed for the installation.
All fasteners must be mounted securely into solid All fasteners must be mounted securely into solid
wood. wood.
TOOLS AND MATERIALS:
Phillips
Hex Wrench
Screwdriver
(Included)
Tape Measure
Drill Bits
TABLE OF CONTENTS
24" hardware installation.......................................Page 2
36" hardware installation.......................................Page 4
48" hardware installation.......................................Page 6
60" hardware installation.......................................Page 8
72" hardware installation.......................................Page 10
Battista Cabinet Door Hardware Installation Instructions
Drill
Level
Pencil
1
