Wiremap
Detect Split Pairs with Wiring Check
Cable Length
Get NVP-Enhanced Measurement Accuracy
Direction
Identify Up to 21 Cable Destinations
n
w
i
t
h
n
w
i
t
h
m
e
n
t
u
m
e
n
t
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hioki LAN CABLE HiTESTER
Summary of Contents for Hioki LAN CABLE HiTESTER
- Page 1 LAN CABLE HiTESTER 3665 Wiremap Detect Split Pairs with Wiring Check Cable Length Get NVP-Enhanced Measurement Accuracy Direction Actual Size Identify Up to 21 Cable Destinations...
- Page 2 Wide Extremely Just connect a cable, and Check all parameters such as wiremap, Intuitive press the TEST button direction and cable length at a glance. Screen Direction (ID No.) Identify the terminator ID here. Cable Length Obtain a record of the entire length of the cable, or up to the point where the cable is dam- aged.
- Page 3 Split pairs appear to be properly a tester capable of detecting split pairs is indispensable. connected to the untrained eye, and cannot be detected with continuity The HIOKI 3665 can do the job for you properly and accu- testing. rately by also detecting split pairs.
- Page 4 Compatible connectors RJ-45 plugs Measurement Items Wiring condition and shielding can be confirmed using the HIOKI TERMINATOR 9690 [Wiremap] Detectable errors: open, short, reversed, transposed, split pairs and other miswiring Measurable lengths: 2 to 300 m, 6.6 to 984 ft [Cable Length] Measurement accuracy: ±4% rdg.
