Item #1003 545 436
1003 421 784
Model #A101004500
USE AND CARE GUIDE
TURNBERRY 10 FT X 12 FT GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
WWW.HAMPTON.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY TURNBERRY A101004500
Summary of Contents for HAMPTON BAY TURNBERRY A101004500
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Warranty ................. 2 Hardware Included ..............3 What is Covered ...............2 Package Contents ..............4 What is Not Covered ..............2 Assembly ............... 6 Care and Cleaning ............23 Safety Information More than two people are required for this assembly. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 5 Pre-Assembly (continued) Part Part Number Description Quantity P000200290 Post 1 P000200289 Post 2 P006300055 Cross panel P000400609 Long cross beam P000400610 Short cross beam P005700259 Long mosquito netting bar 1 P005700260 Long mosquito netting bar 2 P005700261 Short mosquito netting bar 1 P005700262 Short mosquito netting bar 2 P000600898...
-
Page 6: Assembly
Assembly Assembling the Cross Panels Connect 2 sets of Cross Panels (B1) with the long cross beams (B2) using screws (DD). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 7 Assembly Assembling the Cross Panels Connect another 2 sets of Cross Panels (B1) with the short cross beam (B3) using screws (DD). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Assembly Assembling Mosquito Netting Bars Connect the Long mosquito netting bar 1 (C1) with Long mosquito netting bar 2 (C2). Connect the Short mosquito netting bar 1 (C3) with Short mosquito netting bar 2 (C4) . NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 9 Assembly Attaching the Mosquito Netting Bars Attach the assembled Long Mosquito Bars (C1&C2) to the Cross Beam (B1) using bolts (AA). Attach the Short Mosquito Bar (C3&C4) in the same way . NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 10 Assembly Assemble the Post 1 and Post 2 Screw the Post 2 (A2) on Post 1 (A1) using bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 11 Assembly Attaching the Crossbeams Attach the Post 1 (A1) to the assembled Cross Beams (B1&B1) using bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Assembly Attaching the Crossbeams Attach the Post 1 (A1) to the assembled Cross Beams (B1&B1) using bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 13 Assembly Assembling the Oblique Tubes Connect the Upper oblique tube (D1), Middle oblique tube (D2) and Bottom oblique tube (D3) using the spring button on the parts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. D2 D3 WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 14 Assembly Assembling the Middle Tubes Connect the Bottom long middle tube (E2) and Upper long middle tube (E1) using the spring button on the parts. Connect the Bottom short middle tube (F2) and Upper short middle tube (F1) using the spring button on the parts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 15 Assembly Attaching the Oblique Tube and Hook Inset the Upper oblique tubes (D1) to the Big roof connector (G), then Screw the Hook (K) to the Big roof connector (G). Insert the Bottom oblique tube (D3) to the Post 1 (A1). NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 16 Assembly Attaching the Middle Tubes Insert the assembled Long middle tube (E1) to the Big roof connector (G), insert the Bottom long middle tube (E2) to the Short cross beam (B3). Insert the assembled Short middle tube (F1) to the Big roof connector (G), insert the Bottom short middle tube (F2) to the Long cross beam ...
- Page 17 Assembly Assembling the Small Roof Deeply inert the Small roof oblique tube (I) to the Small roof connector (H) to the end (Fig.1), put the small canopy on the small roof and align the corners (Fig.2). Screw the Top decoration (J) on the roof (Fig.3)，pull the Small roof oblique tube (I) back to fit the holl. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 18 Assembly Attaching the Small Roof Put the big canopy (M) on the assembled big roof (D1), connect the assembled small roof (I) with the big roof (D1) using the spring button on the parts before spread the big canopy (M). NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
- Page 19 Assembly Spreading the Big Canopy Spread the Big canopy (M), and first aligning the 4 corners to the Oblique Tubes (D3). Then aligning the big canopy to the middle tube (E1&E2). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 20 Assembly Attaching the Curtain and Netting Hang the Private Curtain (O) and the Mosquito Netting (N) on the Mosquito Netting Bar (C1, C2, C3, C4) using Plastic Ring (CC). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 21 Assembly Securing the Gazebo Secure the assembled gazebo to the lawn with the Stakes (BB). It is recommended for anchoring on wood or concreate surface for more stability using setscrew (Purchased separately) NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTON.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 22: Care And Cleaning
Care and Cleaning □ Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered by the warranty. - Page 23 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
