USE AND CARE GUIDE
FARRINGTON 10 FT. X 12 FT. HARD TOP GAZEBO - GRAPHITE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-841-1350
WWW.HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality products
designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton
Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FARRINGTON A102001702 and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY FARRINGTON A102001702

Summary of Contents for HAMPTON BAY FARRINGTON A102001702

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Hardware Included ................. 4 Important Safety Instructions ........2 Package Contents ................5 Warranty ................. 3 Assembly ............... 9 Pre-Assembly ..............3 Care and Cleaning ............31 Planning Assembly ................. 3 Important Safety Instructions SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE To reduce the risk of injury to persons:...

  • Page 3: Pre-Assembly

    2 YEAR WARRANTY WHAT IS COVERED This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or workmanship for a period of 2 years.

  • Page 4: Hardware Included

    Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Part Number Description Quantity H100010047 Bolt M6*20 with Washer 198+10 H100010046 Bolt M6*40 with Washer 44+3 H100010059 Bolt M6*45 with Washer H100010073 Bolt M6*60 with Washer H100010074 Bolt M6*75 with Washer 16+1 H050030001 M6 Washer...

  • Page 5: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.
  • Page 6 Pre-Assembly (continued) PACKAGE CONTENTS WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.
  • Page 7 Pre-Assembly (continued) PACKAGE CONTENTS Part Number Part Description Quantity P00020093001 Post P00010057301 Post Base P00610030301 Base Cover P00040173901 Long Side Left Cross Beam P00040174001 Long Side Right Cross Beam P00040174101 Short Side Left Cross Beam P00040174201 Short Side Right Cross Beam P00050226001 Rafter Connector P00050226101...
  • Page 8 Pre-Assembly (continued) PACKAGE CONTENTS Part Number Part Description Quantity P00080052101 Small Roof Rafter Cap P00080052201 Big Roof Rafter Cap P00080052301 Big Roof Middle Beam Cap P00570043901 Left Long Mosquito Netting Rod P00570044401 Right Long Mosquito Netting Rod P00570044501 Left Short Mosquito Netting Rod P00570044601 Right Short Mosquito Netting Rod P00500092201...

  • Page 9: Assembly

    Assembly Attaching the Post and Post Base and Base Cover □ Insert the base cover (C) into the post (A1), connect the post base (B1) with post (A1) using bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
  • Page 10 Assembly (continued) Attaching the Cross Beam □ Insert the middle beam connector 1/2 (G1/G2) into the long side left/right cross beam (D3/D4) and short side left/right cross beam (E3/E4), connect the middle beam connector 1/2 (G1/G2) with long side left/right cross beam (D3/D4) using bolts (EE) and washer(FF) and nut (GG).
  • Page 11 Assembly (continued) Attaching the Post and Long Side Cross Beam □ Connect the post (A1) with long side left/right cross beam (D3/D4) using Bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.
  • Page 12 Assembly (continued) Attaching the Post and Short Side Cross Beam □ Connect the Post (A1) with short side left/right cross beam (E3/E4) using bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: If it is difficult to assemble the long/short cross beam for the short side (E3/E4), loosen the bolts on the post cap (M) before assembly.
  • Page 13 Assembly (continued) Attaching the Brace □ Connect the brace (U) with post (A1) and short side left/right cross beam (E3/E4) and long side left/right cross beam (D3/D4) using bolts (BB). □ Use the wrench (KK) to tighten the bolts. NOTE: If it is difficult to assemble the long/short cross beam for the short side (E3/E4), loosen the bolts on the post cap (M) before assembly.
  • Page 14 Assembly (continued) Attaching the Big Roof Long Connector Tube and Big Roof Short Connector Tube and Big Roof Corner Connector □ Insert the big roof long connector tube (J4) and big roof short connector (J5) into the big roof corner connector (J6) using bolts (AA). □...
  • Page 15 Assembly (continued) Attaching the Big Roof Rafter and Beam Connector 1 □ Connect the big roof rafter (H1) with beam connector 1 (X1) using bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.
  • Page 16 Assembly (continued) Attaching the Big Roof Rafter □ Connect the big roof rafter (H1) with big roof corner connector (J6) and rafter connector (F1) using bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.
  • Page 17 Assembly (continued) Attaching the Middle Beam □ Connect the middle beam (I2) with big roof long connector tube (J4) and big roof short connector (J5) using bolts (AA). □ Connect the middle beam (I2) with middle beam connector 1 (G1) using bolts (DD) and washer(FF) □...
  • Page 18 Assembly (continued) Attaching the Small Roof Rafter and Small Roof Connector and Hook □ Connect the small roof rafter (K) with small roof connector (L) using bolts (AA). □ Insert the hook (N) into the small roof connector (L). □ Use the wrench (KK) to tighten the bolts.
  • Page 19 Assembly (continued) Attaching the Small Roof Rafter □ Insert the small roof rafter (K) into the big roof corner connector (J6) using bolts (AA). □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. STEP 1 STEP 2 WWW.HOMEDEPOT.CA...
  • Page 20 Assembly (continued) Attaching the Short Side Small Roof Panel Flashing and Long Side Small Roof Panel Flashing Connect the small roof rafter (K) with short/long side small roof panel flashing (V1/V2) using bolts (AA). □ □ Use the wrench (KK) to tighten the bolts. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
  • Page 21 Assembly (continued) Attaching the Long Side Small Roof Panel and Short Side Small Roof Panel □ Put the long/short side small roof panel (P1/P2) on the top, connect the small roof rafter (K) with long/short side small roof panel (P1/P2) using bolts (AA).
  • Page 22 Assembly (continued) Attaching the Small Roof Rafter Cap and Small Top Cover □ Put the small roof rafter cap (S1) and small top cover (M) on the top, connect the small roof rafter cap (S1) with small roof rafter (K) using bolts (BB) and rubber washer (HH), connect small top cover (M) with small roof connector (L) using bolts (AA) and rubber washer (HH).
  • Page 23 Assembly (continued) Attaching the Small Beam and Beam Connector 1/2 □ Insert the beam connector 2 (X2) into the long/short side small beam (W1/W2), connect the beam connector 2 (X2) with long/short side small beam (W1/W2) and middle beam (I2) using bolts (AA). □...
  • Page 24 Assembly (continued) Attaching the Mosquito Netting Rod □ Connect the big roof rafter (H1) with left/right long mosquito netting rod (T5/T6) and left/right short mosquito left/right long mosquito netting rod (T5/T6) and left/right short mosquito netting rod (T7/T8) using bolts (AA). □...
  • Page 25 Assembly (continued) Attach the Big Roof Panel Flashing and Beam Connector 1/2 □ Insert beam the short side big roof left/right panel flashing (V3/V4) and long side big roof left/right panel flashing (V5/V6) into the connector 2 (X2), connect above using bolts (AA), connect the beam connector 2 (X2) with middle beam (I2). □...
  • Page 26 Assembly (continued) Attaching the Roof Panel □ Put the short side big roof left/right up panel (Q1/Q4) and long side big roof left/right up panel (R1/R2) on the top. □ Connect the short side big roof left/right up panel (Q1/Q4) and long side big roof left/right up panel (R1/R2) with big roof rafter (H1) and middle beam (I2) using bolts (AA).
  • Page 27 Assembly (continued) Attaching the Roof Panel □ Put the short side big roof left/right low panel (Q2/Q3) and long side big roof left/right low panel (R3/R4) on the top, □ Connect the short side big roof left/right low panel (Q2/Q3) and long side big roof left/right low panel (R3/R4) with big roof rafter (H1) and middle beam (I2) using bolts (AA).
  • Page 28 Assembly (continued) Attaching the Big Roof Rafter Cap and Big Roof Middle Beam Cap □ Put the big roof rafter cap (S2) and big roof middle beam cap (S3) on the top. □ Connect big roof rafter cap (S2) with big roof rafter (H1) using bolts (BB) and rubber washer (HH). □...
  • Page 29 Assembly (continued) Attaching the Mosquito Netting □ Put the ring (II) on the mosquito netting (V), then put mosquito netting (V) on the left/right long mosquito netting rod (T5/T6) and left/right short mosquito netting rod (T7/T8), tie the mosquito netting (V) into the post (A1), the ring (II) quantity assigned is as shown. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
  • Page 30 Assembly (continued) Attaching the Stake □ Lift the post base (B1) and secure the assembled gazebo using stakes (JJ), assembly completed. WWW.HOMEDEPOT.CA Please contact 1-800-841-1350 for further assistance.

  • Page 31: Care And Cleaning

    Care and Cleaning □ Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered by the warranty.
  • Page 32 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 WWW.HOMEDEPOT.CA Retain this manual for future use.
