Item #1001 208 267
Model #A101002300
USE AND CARE GUIDE
VERADO GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
WWW.HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERADO A101002300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAMPTON BAY VERADO A101002300

Summary of Contents for HAMPTON BAY VERADO A101002300

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning assembly ..............3 Safety Information ............2 Warranty ................. 2 Hardware Included ..............3 What is Covered ...............2 Package Contents ..............4 What is Not Covered ..............2 Assembly ............... 5 Care and Cleaning ............25 Safety Information Two people are required for this assembly.

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts.

  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 5 Pre-Assembly (continued) Part Part Number Description Quantity P001000032 Decoration P000500767 Small Connector P000500768 Big Connector P005800126 Hook P000600947 Top Oblique Beam P000600948 Long Oblique Beam P000600949 Short Oblique Beam P000600950 Bottom Oblique Beam P000600951 Short Middle Bean P000601045 Bottom Short Middle Bean P000600952 Long Middle Beam P000601046...

  • Page 6: Assembly

    Assembly Attaching the Stake panels  Insert the Stake Panel (R) on the Screen Panel (Q). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 7 Assembly (continued) Assembling the Long Cross Beam  Insert the Side Cross Beams (L) to the Long Cross Beam (K). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8 Assembly (continued) Connecting the Long Cross Beam with Screen Panels  Insert the assembled Long Cross Beam (K&L) to the Screen Panel (Q). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 9 Assembly (continued) Connection the Short Screen Panels  Insert the Short Cross Beam (M) to the Screen Panel (Q). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Assembly (continued) Attaching Mosquito Netting Bars  Attach the Mosquito Netting Bar (N&O&P) on the Cross Beam (K&M) using Bolts (AA). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 11 Assembly (continued) Attaching Top Oblique Beams  Insert the Top Oblique Beam (E) to the Big Connector (C). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 12 Assembly (continued) Connecting the Oblique Beams  Insert the Oblique Beam (F&G) to the Bottom Oblique Beam (H). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 13 Assembly (continued) Attaching the Oblique Beams  Insert top of the assembled Oblique Beam (F&G) to the Top Oblique Beam (E). Inert the bottom of the assembled Oblique Beam (F&G) to the Screen Panel (Q). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 14 Assembly (continued) Assembling Middle Beams  Insert the Bottom Short Middle Bean (I2) into Short Middle Bean (I1). Insert the Bottom Long Middle Bean (J2) into Short Middle Bean (J1). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 15 Assembly (continued) Attaching Middle Beams  Insert the top of the Middle Beams (I&J) to the Big Connector (C), Insert the bottom of the Middle Beams (I&J) to the Cross Beam (K&M). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 16 Assembly (continued) Putting the Big Canopy  Put the Big Canopy (U) on the roof, do not spread it now. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 17 Assembly (continued) Assembling the small roof  Insert the Small Oblique Beam (S) to the small connector (B). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 18 Assembly (continued) Attaching the Small Canopy  Attach the Small Canopy (T) to the Small Roof, aligning the corners and stretching it to fit. Close the netting. NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 19 Assembly (continued) Attaching the Decoration  Screw the Decoration (A) to the Small Top Connector (B). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 20 Assembly (continued) Attaching the Small Roof  Attach the assembled small roof by inserting the Small Oblique Beam (S) to the Top Oblique Beam (E). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 21 Assembly (continued) Spreading the Big Canopy  Spread the Big Canopy (U), aligning the corners where it has no hand loop to the Oblique Beam (H), aligning the corner where it has a hand loop. Close the valance at the corners.. NOTE: To avoid destroying the finish, do not put the parts on the ground directly.
  • Page 22 Assembly (continued) Attaching the Hook  Screw the Hook (D) to the Big Connector (C). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 23 Assembly (continued) Securing the Gazebo  Hang the Private Curtain (W) on the Cross Beams (K&L&M) and Screen Panel (Q) using Ring (CC); Hang the Mosquito Netting (V) on the Mosquito Netting Beam (N&O&P) using Ring (CC). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 24 Assembly (continued) Securing the Gazebo  Secure the assembled gazebo to the lawn with the Stakes (BB).  It is recommended for anchoring on wood or concreate surface for more stability using setscrew (Purchased separately). NOTE: To avoid destroying the finish, do not put the parts on the ground directly. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.

  • Page 25: Care And Cleaning

    Care and Cleaning □ Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered by the warranty.
  • Page 26 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON WWW.HOMEDEPOT.CA Retain this manual for future use. WWW.HAMPTONBAY.CA Please contact 1-855-HD-HAMPTON for further assistance.
