Vendor: S000238
ASSEMBLY INSTRUCTIONS
CORONA ENTERTAINMENT UNIT
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR CORONA ENTERTAINMENT UNIT
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
ASSEMBLY INSTRUCTIONS:
Please check contents and read instructions carefully before commencing assembly
To avoid damages assemble the item on a soft, clean surface
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn
DO NOT use this item unless all fixings are secured
Always use on a level, even surface
It is recommended that two people handle and assemble the item
CARE & MAINTENANCE: To enjoy your furniture for many years please follow our recommendations
below:
This product is manufactured in pine which is a wood with natural characteristics including knots, grains,
clusters or indentations
On unpacking the item you may notice an odour due to the production process. However, this will disappear
after a period of time.
Do not place the item next to a radiator or direct sunlight – this item is manufactured in pine but is susceptible
to temperature change. It is recommended an even room temperature be maintained with no sudden
fluctuations.
Do not place hot or cold items directly onto the surface of the item – always use a placemat or marking will
occur
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water, detergents,
aerosol sprays or any polish. The use of these materials would invalidate any claims.
You may wish to retreat the surface to maintain the original finish – this can be done using block wax (un-
perfumed). Please follow the manufacturer's instructions carefully
Do not place the item onto wet or damp flooring as staining may occur to the floor
Periodically check all screws & fixings to ensure they are secure
DO NOT push the item as this will damage the base
Keep any sharp objects away from the item
www.birlea.com
Page 1 of 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the CORONA and is the answer not in the manual?

Questions and answers

Summary of Contents for Birlea CORONA

  • Page 1 Vendor: S000238 ASSEMBLY INSTRUCTIONS CORONA ENTERTAINMENT UNIT IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR CORONA ENTERTAINMENT UNIT PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE ASSEMBLY INSTRUCTIONS: Please check contents and read instructions carefully before commencing assembly To avoid damages assemble the item on a soft, clean surface HEALTH &...
  • Page 2 Vendor: S000238 Parts List Hardware List Part Description Part Description Top Panel Wooden Dowel Right Panel 14 mm Screw Left Panel 30 mm Screw Centre Panel 35 mm Screw Base Panel 19 mm Bolt Shelf Metal Dowel Back Panel Locking Nut Right Front Frame Handle Left Front Frame...
  • Page 3 Vendor: S000238 Step 1: Insert the right panel (2) into the right front frame (8) ensuring the parts are fully pushed together and lined up correctly. Place the cleats (21) between the marks as shown and secure using hardware part D and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 2: Insert the left panel (3) into the right front frame (9) ensuring the parts are fully pushed together and...
  • Page 4 Vendor: S000238 Step 3: Insert hardware part A using a small mallet (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 4: Insert hardware part F to the top panel (1) using a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 4 of 11...
  • Page 5 Vendor: S000238 Step 5: Insert hardware parts F and M in the right panel (2) and left panel (3) using a screwdriver and small mallet (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 6: Insert hardware parts F and M to both sides of the centre panel (4) using a screwdriver and small mallet (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim...
  • Page 6 Vendor: S000238 Step 8: Attach the centre drawer runner (20) to the centre panel (4) using hardware part D and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 9: Connect the frame sections as shown.
  • Page 7 Vendor: S000238 Step 11: Attach a base panel (5) using hardware part G and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 12: Attach the centre panel (4) using hardware part G and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 13: Attach the remaining base panel (5) using hardware part G and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim...
  • Page 8 Vendor: S000238 Step 14: Attach the right panel (2) using hardware part G and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 15: Attach the top panel (1) using hardware part G and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 16: Attach the front plinth (22) and side plinths (23) using hardware part C and a screwdriver (not provided)
  • Page 9 Vendor: S000238 Step 17: Assemble the drawer components using hardware parts C, E and H with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 18: Attach hardware parts H and J to the door (14) using hardware parts B and E with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 19: Centralise the door (14) then secure in position using hardware part B and a screwdriver (not...
  • Page 10 Vendor: S000238 Step 20: Secure hardware part K using hardware part B and a screwdriver, making sure the small wheels are flush with the edge of the base. Insert hardware part L to hardware part K ensuring they are level. Push the door (4) against the parts, this will make a small mark on the door.
  • Page 11 Step 23: Attach the back panel (7) using hardware part N and a small mallet (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim For complete product information, images and dimension diagrams please visit www.birlea.com Page 11 of 11...
