Vendor: S000238
ASSEMBLY INSTRUCTIONS
CORONA 4' HIGH END BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORONA 4' HIGH
END BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
This product is manufactured in pine which has natural characteristics including knots, grains, clusters or
indentations.
On unpacking you may notice an odour due to production processes. Tthis will disappear after a period of
time.
DO NOT place the item next to a radiator or direct sunlight – this item is manufactured in pine but is
susceptible to temperature change. It is recommended an even room temperature be maintained with no
sudden fluctuations.
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water,
detergents, aerosol sprays or any polish as use of these materials would invalidate any claims.
To retreat the surface use block wax (un-perfumed). Please follow the manufacturer's instructions carefully
DO NOT place the item onto wet or damp flooring as staining may occur to the floor
www.birlea.com
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CORONA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Birlea CORONA

  • Page 1 Vendor: S000238 ASSEMBLY INSTRUCTIONS CORONA 4’ HIGH END BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORONA 4’ HIGH END BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT jump on this bed frame.
  • Page 2 Vendor: S000238 Parts List Hardware List (found in box 2) Part Description Part Description Headend Panel 30 mm Wooden Dowel Footend Panel 40 mm Wooden Dowel Left Headend Post 16 mm Screw Right Headend Post 2 35 mm Screw Right Footend Post 32 mm Bolt Left Footend Post Slat...
  • Page 3 Vendor: S000238 Step 1: Attach the support legs (8) to the centre rail (10) using hardware parts G and M. Insert hardware part B using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Insert hardware part A using a small mallet (not provided).
  • Page 4 Vendor: S000238 Step 4: Attach the left footend post (6) and right footend post (5) to the footend panel (2) using hardware parts H and M. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Secure hardware part L using hardware part C and a screwdriver (not provided).
  • Page 5 Vendor: S000238 Step 7: Join the two sections together using hardware parts J, K and M. Secure the centre rail (10) using hardware parts E and F. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 8: Secure the slats (7) using hardware parts D and N with a screwdriver (not provided).
  • Page 6 • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
  • Page 7 Vendor: S000238 Page 7 of 7...
