Birlea CORFU Assembly Instructions Manual

Bunk bed

Advertisement

Quick Links

Vendor: S000053
ASSEMBLY INSTRUCTIONS
CORFU BUNK BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORFU BUNK
BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
Be aware of the danger of young children (under 6) falling from the upper bunk. It is not advisable for
children under the age of 6 to sleep on the top bunk
This bed frame complies to EN 747 – 1&2 (2012)
CAUTION: There is the risk of strangulation to children from items such as string, ropes, cords, harnesses and
belts hanging from the bed frame
WARNING: Children can become trapped between the bed and the wall. To avoid risk of serious injuries please
be aware of the distance between the wall and the top safety barrier
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
Recommended maximum mattress height for top bunk is 200 mm
www.birlea.com
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the CORFU and is the answer not in the manual?

Questions and answers

Summary of Contents for Birlea CORFU

  • Page 1 Vendor: S000053 ASSEMBLY INSTRUCTIONS CORFU BUNK BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORFU BUNK BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT jump on this bed frame. DO NOT use this bed frame if any parts are missing, damaged or worn.
  • Page 2 Vendor: S000053 Parts List Hardware List (found in box 2) Part Description Part Description Upper Frame M8 Metal Square Nut Bottom Frame M8 x 95 mm JCBC Screw Bottom Base M6 x 45 mm JCBC Screw Top Base M6 x 15 mm JCN Nut Back Rail M6 x 80 mm JCBC Screw Front Rail...
  • Page 3 Vendor: S000053 Step 1: Insert hardware part I to the bottom frame (2) then slot the bottom base (3) into the brackets on the bottom frame. Place the frame connectors (8) onto the bottom frame then insert the upper frames (1) by facing hole to hole as shown in views AA and AB.
  • Page 4 Vendor: S000053 Step 3: Slot the top base (4) into the brackets on the upper frame (1) and secure using hardware parts A and B at the four corners. Then secure the bottom base (3) using hardware parts A and B at the four corners but do not tighten the screws yet.
  • Page 5 Vendor: S000053 Step 5: Secure the horizontal tube of the front rail (6) to the upper frame (1), then secure the front rail to the top base (4) using hardware part E. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 6: Assemble the ladder (7) using hardware parts F, G and H.
  • Page 6: Additional Information

    • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
