ASSEMBLY INSTRUCTIONS
3 DRAWER CONSOLE TABLE WITH SHELF
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR 3 DRAWER
CONSOLE TABLE WITH SHELF.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY INSTRUCTIONS:
Please check contents and read instructions carefully before commencing assembly.
To avoid damages assemble the item on a soft, clean surface.
Assemble in the room of use.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn.
DO NOT use this item unless all fixings are secured.
Always use on a level, even surface.
It is recommended that two people handle and assemble the item.
Keep small parts out of the reach of children.
CARE & MAINTENANCE:
This product is manufactured in pine which is a wood with natural characteristics including knots, grains,
clusters or indentations.
On unpacking the item you may notice an odour due to the production process, however, this will disappear
after a period of time.
DO NOT place the item next to a radiator or direct sunlight as this item is susceptible to temperature
change. It is recommended to maintain an even room temperature with no sudden fluctuations.
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water,
detergents, aerosol sprays or any polish as the use of these materials would invalidate any claims.
You may wish to re-treat the surface to maintain the original finish. This can be done using block wax (un-
perfumed). Please follow the manufacturer's instructions carefully.
DO NOT place the item onto wet or damp flooring as staining may occur to the floor.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the item as this will damage the base.
Keep any sharp objects away from the item.
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Corona series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Birlea Corona series

  • Page 1 ASSEMBLY INSTRUCTIONS 3 DRAWER CONSOLE TABLE WITH SHELF IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR 3 DRAWER CONSOLE TABLE WITH SHELF. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY INSTRUCTIONS: Please check contents and read instructions carefully before commencing assembly. To avoid damages assemble the item on a soft, clean surface.
  • Page 2 Parts List Hardware List Part Description Part Description Top Panel 3.5 x 35 mm Screw Front Panel 8 x 25 mm Wooden Dowel Back Panel 3.5 x 35 mm Screw Side Panel 3/16 x 5/8 Bolt Leg Pack Handle Leg Pack ** You will need a small mallet and a screwdriver.
  • Page 3 Step 1: Insert hardware part B using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Attach one leg (5) and one leg (6) to a side panel (4) using hardware part A. Repeat for the remaining legs and side panel.
  • Page 4 Step 3: Insert the side drawer runners (7) and centre drawer runner (13) to the front panel (2) and back panel (3) using hardware part A and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 4: Attach the front panel (2), back panel (3) and shelf (8) to an assembled end frame using hardware part A and a screwdriver (not provided).
  • Page 5 Step 5: Attach the remaining assembled end frame using hardware part A and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 6: Attach the top panel (1) using hardware part A and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
  • Page 6: Additional Information

    Step 7: Assemble the drawer components using hardware parts C, D and E with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 8: Insert the assembled drawers and secure using hardware part B and a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
