Vendor: S000238
ASSEMBLY INSTRUCTIONS
CORONA 2 DOOR 1 SHELF FLAT SCREEN TV UNIT
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORONA 2 DOOR
1 SHELF FLAT SCREEN TV UNIT.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY INSTRUCTIONS:
Please check contents and read instructions carefully before commencing assembly.
To avoid damages assemble the item on a soft, clean surface.
Assemble in the room of use.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn.
DO NOT use this item unless all fixings are secured.
Always use on a level, even surface.
It is recommended that two people handle and assemble the item.
Keep small parts out of the reach of children.
CARE & MAINTENANCE:
This product is manufactured in pine which is a wood with natural characteristics including knots, grains,
clusters or indentations.
On unpacking the item you may notice an odour due to the production process, however, this will disappear
after a period of time.
DO NOT place the item next to a radiator or direct sunlight as this item is susceptible to temperature
change. It is recommended to maintain an even room temperature with no sudden fluctuations.
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water,
detergents, aerosol sprays or any polish as the use of these materials would invalidate any claims.
You may wish to re-treat the surface to maintain the original finish. This can be done using block wax (un-
perfumed). Please follow the manufacturer's instructions carefully.
DO NOT place the item onto wet or damp flooring as staining may occur to the floor.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the item as this will damage the base.
Keep any sharp objects away from the item.
www.birlea.com
Page 1 of 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the Corona and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Birlea Corona

  • Page 1 Vendor: S000238 ASSEMBLY INSTRUCTIONS CORONA 2 DOOR 1 SHELF FLAT SCREEN TV UNIT IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CORONA 2 DOOR 1 SHELF FLAT SCREEN TV UNIT. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY INSTRUCTIONS: Please check contents and read instructions carefully before commencing assembly.
  • Page 2 Vendor: S000238 Parts List Hardware List Part Description Part Description Top Panel Wooden Dowel Right Panel 14 mm Screw Left Panel 30 mm screw Centre Panel 35 mm Screw Shelf 19 mm Bolt Base Panel Handle Back Panel Hinge Right Front Frame Clip Left Front Frame Plug...
  • Page 3 Vendor: S000238 Step 1: Insert the right panel (2) into the right front frame (8) ensuring parts are fully pushed together and correctly lined up. Place the cleats (14) between the marks shown and secure using hardware part C and a screwdriver (not provided).
  • Page 4 Vendor: S000238 Step 2: Insert the left panel (3) into the left front frame (9) ensuring parts are fully pushed together and correctly lined up. Place the cleats (14) between the marks shown and secure using hardware part C and a screwdriver (not provided).
  • Page 5 Vendor: S000238 Step 4: Attach the centre panels (4) to the base panel (6) using hardware part D and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Connect the top front frame (10) to the left panel (3).
  • Page 6 Vendor: S000238 Step 6: Join the two assembled sections together, securing using hardware part D and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 7: Attach the right panel (2) using hardware part D and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
  • Page 7 Vendor: S000238 Step 8: Attach the top panel (1) using hardware part D and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 9: Attach the side plinths (13) and front plinth (12) using hardware part C. Secure hardware part L using hardware part B.
  • Page 8 Vendor: S000238 Step 10: Insert hardware part K using a small mallet (not provided) then position the shelf (5) as shown. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 11: Attach hardware part G to the doors (11) using hardware part B, then secure hardware part F using hardware part E.
  • Page 9: Additional Information

    • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
