IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE
1 DRAWER BEDSIDE SILVER OAK.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this Bedside if any parts are missing , damaged or worn.
DO NOT use this Bedside unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this item is placed on a non-carpeted floor you must place some protection under all legs to stop
the bedside from moving. If this is not adhered to there is no guarantee if the bedside collapses.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bedside as this will damage the legs.
Always lift the bedside with two people to reposition.
Keep any sharp objects away from the bedside.
ASSEMBLY INSTRUCTIONS
CONRAD 1 DRAWER BEDSIDE SILVER OAK
www.birlea.com
ASSEMBLING OR USING YOUR CONRAD
Vendor: S000369
Page 1 of 9
Advertisement
Related Manuals for Birlea CONRAD CON1BSSLOK
Summary of Contents for Birlea CONRAD CON1BSSLOK
- Page 1 Periodically check all screws & fixings to ensure they are secure. DO NOT push the bedside as this will damage the legs. Always lift the bedside with two people to reposition. Keep any sharp objects away from the bedside. www.birlea.com Page 1 of 9...
- Page 2 Vendor: S000369 Hardware 4 x D 12 x A 12 x B 5 x C 1 x E 2 x F Cam Lock Quickfit Screw Screw Wedge Handle Bolt 4x30mm 6x30mm 12 x G 1 x H 8 x I 4 x J 4 x K 6 x L...
- Page 3 Vendor: S000369 Step 1 DRAWERS Fix panels 7, 8 and 9 together using screws C. C x 4 Fit base panel 11 into grooves between panels 7 and 9. Fit quickfit screws B to front panel 10. Insert cam locks A to A x 4 panels 7 and 9.
- Page 4 Vendor: S000369 Step 2 Fix outer drawer runners N and O to panels 2 and 3 using screws G. G x 6 N x 1 O x 1 A x 2 Step 3 B x 2 Insert quickfit screws B and wooden dowels I to panel 2.
- Page 5 Vendor: S000369 Step 5 Slide back panel 6 into slots in between panels 2 and 3. Step 6 Fit quickfit screws B to panel 1. Fix bracket Q to underside of panel 1 using screw R. B x 4 Q x 1 R x 1 Page 5 of 9...
- Page 6 Vendor: S000369 Step 7 Insert wooden dowels I panels 2 and 3. Insert cam locks A to panels 2 and 3. A x 4 I x 4 Lower panel 1 into place and turn cam locks to tighten. Step 8 Fit wedges D to back of unit to secure back panels.
- Page 7 Vendor: S000369 Step 9 Fix parts 12 and 13 together using bolts L, as shown. L x 6 Step 10 Fix joined leg parts (Step 9) to base of assembled unit using screws J, as shown. J x 4 Page 7 of 9...
- Page 8 Vendor: S000369 Step 11 For extra stability, it is recommended that you fix your bedside table to the wall using the additional hardware C and P, as shown. Screw C is fixed from inside the unit, through the bracket and into the wall plug P. C x 1 Should you choose not to affix the product to the wall, serious injury may be caused if the product tips over.
-
Page 9: Additional Information
If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on Instagram. Page 9 of 9...
