Wood-Mizer
Sawmill
Safety, Setup, Operation
& Maintenance Manual
LX450-RA
rev. A1.05
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #2336
