G18 Engine
Safety, Operation, Maintenance
& Parts Manual
LT25/LT27
rev. E1.00 - E3.05
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
January 2004
Form #1050

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer LT25

  • Page 1 G18 Engine Safety, Operation, Maintenance & Parts Manual LT25/LT27 rev. E1.00 - E3.05 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. January 2004 Form #1050...
  • Page 2 Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...
  • Page 3: Table Of Contents

    Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL 1-IV SECTION 1 OPERATION Starting The Engine................1-1 SECTION 2 MAINTENANCE Maintenance ...................2-1 Safety......................2-1 Cooling System ..................2-2 Air Filter & Pre-Cleaner.................2-2 Fuel Filter ....................2-2 Battery ....................2-3 RPM Adjustments ..................2-3 Miscellaneous Maintenance ..............2-4 SECTION 3 REPLACEMENT PARTS Fuel Tank....................3-1...
  • Page 4: About This Manual 1-Iv

    SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment.
  • Page 5: Operation

    Starting The Engine SECTION 1 OPERATION Starting The Engine DANGER! Always be sure the blade is disengaged and clear the path of the blade before starting the engine. Failure to do so will result in serious injury or death. DANGER! Operate your engine/machine only in well ventilated areas.Exhaust gases can cause nausea, delirium and potentially death unless adequate ventilation is present.
  • Page 6: Maintenance

    Maintenance SECTION 2 MAINTENANCE Maintenance Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth- erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals.
  • Page 7: Cooling System

    Maintenance Cooling System This symbol identifies the interval (hours of operation) at which each maintenance pro- cedure should be performed. "AR" signifies maintenance procedures which should be performed as required. Cooling System Wash the engine or brush off sawdust and debris every 50 hours of operation. Clean the grass screen, cooling fins, and external surfaces.
  • Page 8: Battery

    Maintenance Battery Battery Check the battery electrolyte level every 50 hours of operation. See manufacturer’s man- ual for instructions. DANGER! Batteries expel explosive gases. Keep sparks, flames, burning cigarettes, or other ignition sources away at all times. Always wear safety goggles and a face shield when working near batteries. Failure to do so will cause serious injury.
  • Page 9: Miscellaneous Maintenance

    Maintenance Miscellaneous Maintenance 3. Engage the clutch handle to throttle the engine and measure the high-end RPM. The high-end RPM is factory-set at 3750. Readjust the throttle cable if necessary to increase or reduce the high-end engine speed. Miscellaneous Maintenance Inspect the spark plugs every 100 hours of operation.
  • Page 10: Replacement Parts

    Replacement Parts Fuel Tank SECTION 3 REPLACEMENT PARTS Fuel Tank 3H0415C DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. TANK ASSEMBLY, 5-GALLON RED GASOLINE A12285 Tank, 5-Gallon Red Fuel P12167  Pickup, 9" Fuel P12172 Cap, 3 or 5-Gallon Fuel Tank P09683 Fitting, 1/4"...
  • Page 11: Engine Mount Assembly

    Replacement Parts Engine Mount Assembly Engine Mount Assembly 3H0509-3 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. MOUNT KIT, KOHLER ENGINE 016319 Mount Weldment, Kohler Engine 014514  BUSHING ASSEMBLY, MOTOR MOUNT 016380 Bushing, 2” OD x 2” 016378 ...
  • Page 12: Engine Assembly

    Replacement Parts Engine Assembly Engine Assembly 11 12 250051 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. COVER, ENGINE P12393 ENGINE ASSEMBLY, 18HP KOHLER 017626 Engine, 18HP Kohler #PA62590 016899  Filter, Kohler Air #47-083-03 006907 Pre Cleaner, Kohler #24-083-02 006931 Plug, RC12YC Kohler Spark #12-132-02 P12757...
  • Page 13 Replacement Parts Engine Assembly Bracket, Throttle Cable Mount S12312 Spring, .5” x .08” x 1 3/8” Extension 015952 Bracket, G25 Throttle 015964 Bolt, #10-24 x 5/8” Hex Head F05004-18 Nut, #10-24 Self-Locking F05010-14 Hose, 7" Oil Drain P10082 Cap, Oil Drain 3/8" Pipe P04332 Oil, 10W30 Type CD L04869-1...
  • Page 14: Engine Pulley Guards

    Replacement Parts Engine Pulley Guards Engine Pulley Guards 250052B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. GUARD WELDMENT, KOHLER ENGINE PULLEY 015343 GUARD, G20/G25 SIDE ENGINE PULLEY 015962 BOLT, 1/4-20 X 3/4” HEX HEAD WITH CONICAL WASHER F05005-134 25G1801doc031120 Replacement Parts...
  • Page 15: Index

    INDEX maintenance air cooling system battery fuel filter miscellaneous RPM adjustments parts list engine assembly engine mount assembly fuel tank pulley guards starting Index 25G1801doc031120...
