- Page 1 Premium Public Displays Installation Notes Version 1.1 The use of diagrams and illustrations in the manual for reference only, actual product may be different. Product design and specifications are subject to change without notice Copyright © DynaScan Technology, Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Operating Temperature ..............................9 Ventilation (Fan-cooled models) ..........................10 Enclosures .................................. 11 Using a Cooling & Heater Solution ......................... 11 In-Window Applications .............................. 13 Media Player Location ..............................14 Contact Us .................................. 15 DynaScan Premium Public Display Installation Notes 1... -
Page 3: Handling
Extra care should be taken when handling narrow bezel LCDs. An impact with the edges could cause the LCD panel to crack. Adhere to the handling signs printed on the Box. Use a pallet jack when moving the display . DynaScan Premium Public Display Installation Notes 2... - Page 4 Do not drop or lay the LCD box on its side. Do not sit or lean on the box. DynaScan Premium Public Display Installation Notes 3...
-
Page 5: Unboxing The Display
Unboxing the Display 1. Cut packing strap off the box. 2. Remove plastic clips by pulling tab. 3. Remove the top packaging by lifting up. 4. Remove the protective poly bag. DynaScan Premium Public Display Installation Notes 4... - Page 6 6. With two hands grabbing the set, move the display. bottom packing when lifting up the display. 7. For larger models, use a lifting tool when unpacking 8. Lay the face of the display downward on a soft, or repackaging. padded surface. DynaScan Premium Public Display Installation Notes 5...
-
Page 7: Wall Mount Installation
The LCD must be properly installed using a wall mount. Incorrect installation may cause injury or damage the equipment. Product warranty does not cover damages caused by improper installation and DynaScan shall not be held responsible in such incident. Refer to the mount manufacturer’s instructions for proper installation. -
Page 8: Wall Mounting
Wall Mounting • A wall mount is not included. Please purchase a VESA Standard wall mount to secure the LCD. DynaScan is not responsible for damages caused by using non-standard wall mounts. • Verify that the mounting location can support the weight of the LCD before installation. -
Page 9: Hanging From A Ceiling
Product warranty does not cover improper installation, modification, or damages caused by natural disasters. • DynaScan recommends hiring certified professionals to evaluate the installation site and mounting operation. • Do not to cover the vent and/or the heat sink in order to ensure proper heat dissipation. -
Page 10: Operating Temperature
Operating Temperature Operating temperature must be maintained between 0°C-40° C (32°F–104°F). To maintain the proper operating temperature, you may consider using a cross flow fan beneath the display as shown below. DynaScan Premium Public Display Installation Notes 9... -
Page 11: Ventilation (Fan-Cooled Models)
To maintain the proper operating temperature, cool air must be allowed to enter the display and hot air must be allowed to exit the display. Obstructing fans and vents, or not providing cool air to the rear of the display can cause the display to overheat. (See below example). DynaScan Premium Public Display Installation Notes 10... -
Page 12: Enclosures
• Use an air filter to prevent dust. (At air inlet and outlet) • For preventing from rust of lead frame in circuit board, operate the heater if relative humidity is too high. DynaScan Premium Public Display Installation Notes 11... - Page 13 Air Curtain Air Curtain HEATER Example 1: Enclosure (Fans Only) Example 2: Enclosure (Heat exchanger) Air Curtain Air Curtain Humidity Sensor CONDITIONER Example 3: Enclosure (Air Conditioner) Example 4: Direct Air Cooling DynaScan Premium Public Display Installation Notes 12...
-
Page 14: In-Window Applications
Electrical lighting such as spotlights can raise the ambient temperature in the area and should be accounted for. • The use of UV and/or IR films on the window may be used to help minimize heat entry. Consult your local integrator for recommendations. Window 10 cm DynaScan Premium Public Display Installation Notes 13... -
Page 15: Media Player Location
If mounting a media player to the rear of the display, be sure to leave a gap between the heat sink and the player device to allow for proper air ventilation. Failure to do so could damage the LCD and/or media player. DynaScan Premium Public Display Installation Notes 14... -
Page 16: Contact Us
NL-6716 AH Ede The Netherlands T. +31 318 648 282 info@dynascaneu.com Asia DynaScan Technology Corp. 66 Hwaya 1st Rd. Kueishan Hwaya Technology Park Taoyuan County 33383 Taiwan T. +886 3 396 0541, x8540 info@dynascan.com.tw DynaScan Premium Public Display Installation Notes 15...
