GVision P17PH-L Specifications

1 7 " T F T L C D M o n i t o r
Advertising Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Audio System
USB HUB
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions ( W x H x D )
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s
P17PH-LW
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
450:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
337.920(H) x 270.336(V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
o
Tilt down: -3 , Tilt up: +15
Analogue VGA,
Composite Video (NTSC/PAL)
D-sub 15 pin (VGA)
DVI-D (option)
RCA, S-video
H. scan 31~80KHz,
V. scan 56 ~ 75Hz
1W/per channel driver
N/A
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Universal power adaptor Input
AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48W
VESA DPMS standard
439 x 461 x 195 mm
530 x 528 x250 mm
6.8kg
C-UL, FCC, CE
Mechanical drawing
P17H-L
Front Side
F l e x i b i l i t y F l e x i b i l i t y
Features :
* High contrast color TFT LCD display supports resolution
up to XGA 1280x1024. Compatible with IBM VGA, VESA
standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Multi signals: VGA, DVI-D, Composite video, S-video
(Auto detection of input signals.)
* Composite video system PAL/NTSC and SECAM
compatible.
o
* Built-in audio system.
* Optional stable photo frame stand base.
* Optional black & white housing.
* Optional VESA mounting.
Optional Accessories :
* Anti-Glare tempered glass.
* Photo stand
Ordering Information :
* P17PH-LW
* P17PH-LE
* P17PH-JW
* P17PH-JE
I/O Ports
Audio in RCA S-Video DC in DVI-D VGA line-in
P17H-J
Front Side
P17PH LW P17PH-LW P17PH-LW
VGA + Video-in
VGA + DVI + Video-in
VGA + Video-in + photo stand
VGA + DVI + Video-in + photo stand
Back Side
