GVision P17BH-AA Specifications

1 7 " T F T L C D M o n i t o r 1 7 " T F T L C D M o n i t o r
POS Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio*
Brightness*
Response Time* ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life (hr)
Stand Base
Input Signals
Signal connector Analog
Digital
Scan Frequency
Audio Systems
USB HUB
Touch Panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Internal Power
Power Consumption
Dimensions(WxHxD)
Carton Dimensions(WxHxD)
Weight (Net)
Certification
* Specifications are subject to change without notice.
o
90
o
-5
o
30
0
Support Angle Asjstment -5
GViSiON USA, INC. phone: 949-586-3338 / fax: 949-586-3398 / www.gvision-usa.com GViSiON USA, INC. phone: 949-586-3338 / fax: 949-586-3398 / www.gvision-usa.com
M e e t s M e e t s
P17BH series
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
500:1 (typical)
2
260 Cd/m (typical)
8 ms (typical)
16.2M
337.9(H) x 270.3(V)
o o
140 (H) x 140 (V)
CCFL x 4
50,000 (typical)
o o
Tilt down: -5 , Tilt up: +90
Analogue VGA
D-Sub 15 pin (VGA)
DVI-D
60/70/72/75 Hz
1W/per channel driver
A type x 2, B type x 1 (optional)
RS232 or USB A type (optional)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
100 ~ 240V, 50~60Hz
1.5A , AC Input
48W
392 x 381.5 x 180 mm
456 x 455 x 228 mm
5 Kg
UL, FCC, CE
Mechanical drawing
Unit : mm
0
~+90
F l e x i b i l i t y F l e x i b i l i t y

Features

* Fashionable housing design with slim bezel
* High contrast color TFT LCD open frame display support
resolution up to XGA 1280x1024. Compatible with IBM
VGA, VESA standards
* Support DDC1/2B for Plug & Play compatibility
* Advanced OSD control for picture quality adjustment
* Stable aluminum stand base supports angle adjustment
0 0
5 ~ +90
* VESA mounting
Optional Accessories
* 3M / ELO / HIGGSTEC touch sensor
* Customized touch solutions acceptable
* Anti-Glare tempered glass
* USB HUB with 2 downstream ports and 1 upstream port
Order Information
* P17BH-AA VGA only
* P17BH-AB VGA+DVI
I/O Ports
AC-in
Front Side
P17BH P1 P17BH 17BH 17BH
series series series
Touch USB HUB Audio-in DVI-D VGA DC-in
Back Side
