GVision MG21AU-G Specifications

21.3" 2 Mega-pixels Monochrome TFT LCD Monitor
Medical Application
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Signal connector Digital
Scan Frequency
Key Control
Stand Base
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Internal Power
Power Consumption
Dimensions Landscape
(WxHxD) Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
Front Side
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s F l e x i b i l i t y
MG21AU-GD
21.3" TFT Monochrome active
matrix panel
0.270(H) x 0.270 (V) mm
UXGA 1600 x 1200
700:1 (Typical )
2
800 Cd/m (Typical )
35 ms
256 gray scales per 1 sub-pixel
(8-bit)(766 gray scales per 1 pixel)
432.0(H) x 324.0(V)
170 (H) x 170 (V)
6 CCFLs
50,000 hrs (min.)
DVI-D
60 Hz
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o
Height +/- 9cm, Swivel +/- 65 ,
o o o
Tilt 5 ~65 , Rotate +/- 90
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
70 watts
481.95x449.97x209.98mm
377.95x539.97x209.99mm
17 Kg
CE, FCC, UL60601-1,
TUV EN60601-1
Mechanical drawing
Back Side
MG21AU GD MG21AU GD MG21AU-GD
y
Features :
* 2 Megapixel format (1200 X 1600, UXGA)
* 21.3 Inch Diagonal Viewing Size
* IPS super wide view angle TFT LCD technology
2
* 800 Cd/m Max. Luminance
* Luminance Stabilization Circuit
* Adjustable Luminance value
* 10-bit Gamma Correction (DICOM Chapter 3.14)
* Built In 90~264 Vac medical grade Power Supply
* CE, FCC, TUV EN 60601-1, UL 60601-1 medical
certification available.
* IPX1 Spilling proof available
* Height, swivel, Tilt, and Rotation adjustable Stand
Optional Accessories :
* Tempered Protection glass
* Color Calibration Kit
Ordering Information :
* MG21AU-GD DVI-D
I/O Ports
DC in DVI
Front Side
U
Back Side
