GVision MA21AU-G Specifications

2 1 . 3 " 2 M e g a - p i x e l s C o l o r T F T L C D
Medical Application
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signal
Signal connector Analog
Digital
Video-in
Scan Frequency
Key Control
Speakers Out (watts)(R/L)
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Internal Power
Power Consumption
Dimensions Landscape
(WxHxD) Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
Front Side
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s
MA21AU-GB
21.3" TFT active matrix panel
in-Plane Switching(IPS)
0.270(H) x 0.270 (V) mm
UXGA 1600 x 1200
400:1 (Typical )
2
250 Cd/m (Typical )
25 ms
16,777,216 colors
432.0(H) x 324.0(V)
170 (H) x 170 (V)
6 CCFLs
50,000 hrs (min.)
o
Height +/- 9cm, Swivel +/- 65 ,
o o o
Tilt 5 ~65 , Rotate +/- 90
Analogue VGA,
Digital,
D-sub 15 pin (VGA)
DVI-D
RCA , S-Video (option)
56/60/70/72/75 Hz
Power on/off with LED, Menu,
Select, Adjustment (+, - )
2.5W / per channel driver (option)
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
70 watts
481.95 x 449.97 x209.98mm
377.95 x 539.97 x 209.99mm
17 Kg
CE, FCC, UL60601-1,TUV EN60601-1
Mechanical drawing
Back Side
F l e x i b i l i t y y
Features :
* 2 Megapixel format (1200 X 1600, UXGA)
* 21.3 Inch Diagonal Viewing Size
* IPS super wide view angle TFT LCD technology
* Luminance Stabilization Circuit
* Adjustable Luminance value
* Gamma Correction (DICOM Chapter 3.14)
* Built In 90~264 Vac medical grade Power Supply
* CE, FCC, TUV EN 60601-1, UL 60601-1 medical
certification available.
* IPX1 Spilling proof available
* Height, swivel, Tilt, and Rotation adjustable Stand
* Multi-Signal Inprts : VGA. DVI, Composite Video,
S-Video (Auto DetectionOF Input Signals).
* NTSC/PAL,Video Systmes compatible
* Support DDC1/2B for Plug & Play Compatibility.
Optional Accessories :
* Anti-Glare Tempered Protection glass
* Color Calibration Kit
Ordering Information :
* MA21AU-GB VGA, DVI-D
* MA21AU-GE VGA, DVI-D, Video, S-Video, Audio
I/O Ports
DC in D-sub
Front Side
MA21AU GB MA21AU GB
DVI Audio in S-Video Cubs Audio Speaker out
Back Side
