GVision MA15BX-A Specifications

15" Color TFT LCD Monitor
Medical Application
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal connector Analog
Digital
Video-in
Scan Frequency
Key Control
Touch Panel
Speakers Out (watts)(R/L)
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power Adapter
Power Consumption
Dimensions Landscape
(HxWxD) Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
90
o
-5
o
30
Support Angle Asjstment -50
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s
MA15BX-AA
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (Typical )
2
250 Cd/m (Typical )
16 ms
16,777,216 colors
304.1 (H) x 228.1 (V)
120 (H) x 100 (V)
2 CCFLs
30,000 hrs
o
Tilt Down: -5 , Tilt Up: +90
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (option)
RCA , S-Video (option)
60/70/72/75 Hz
Power on/off with LED, Menu,
Select, Adjustment (+, - )
Resistive/Capacitive RS-232
or USB (option)
2W / per channel driver(option)
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48 watts
351 x 311.5 x 140mm
440 x 458 x 216 mm
4.5 Kg
CE, FCC, UL60601-1,TUV
EN60601-1
Mechanical drawing
UNiT : mm
o
0 0
~+90
F l e x i b i l i t y y
Features :
* Fashionable Design with Slim bezel
* CE, FCC, TUV EN 60601-1, UL 60601-1 medical
certification available.
* IPX1 Spilling proof Compliant
* High contrast color TFT LCD display support resolution
up to XGA 1024x768.
* Medical grade power adapter.
* Advanced OSD control for picture quality adjustment.
* Stable Aluminum Stand Base with Angle
o
Adjustment -5
* Multi-Signal Inprts : VGA. DVI, Composite Video,
S-Video (Auto Detection of Input Signals).
* NTSC/PAL,Video Systmes compatible
* Support DDC1/2B for Plug & Play Compatibility..
Optional Accessories :
* 3M Capacitive Touch Sensor
* ELO/3M 5 wire Resistive Touch Sensor available
* Anti-Glare Tempered Protection glass
* 2 Watts internal Speakers
Ordering Information :
* MA15BX-AA
* MA15BX-AB
* MA15BX-AE
I/O Ports
Touch
Front Side
MA15BX AA MA15BX-AA MA15BX AA
o o
up to 90
VGA
VGA, DVI-D
VGA, DVI-D, Video, S-Video, Audio,
Audio in DVI-D VGA DC in
Back Side
