GVision MA19BH-A Specifications

19" 1.3 Mega-Pixels Color TFT LCD Monitor
Medical Application
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signal
Signal connector Analog
Digital
Video-in
Scan Frequency
Key Control
Touch Panel
Speakers Out (watts)(R/L)
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Internal Adapter
Power Consumption
Dimensions Landscape
Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
90
o
-5
o
30
Support Angle Asjstment -50
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s
MA19BH-AA
19" TFT active matrix panelIn in-
Plane Switching(IPS)
0.294(H) x 0.294 (V) mm
SXGA 1280 x 1024
600:1 (Typical )
250 Cd/m2 (Typical )
25 ms
16,777,216 colors
376.320(H) x 301.056(V)
170 (H) x 170 (V)
4 CCFLs
40,000 hrs (min.)
o
Tilst own:-5 , Tilt Up:+90
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (option)
RCA , S-video (option)
60/70/72/75 Hz
Power on/off with LED, Menu,
Select, Adjustment (+, - )
Resistive/Capacitive RS-232
or USB (option)
2W / per channel driver(option)
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
48 watts
438(H) x 417.5(W) x 180(D) mm
528(H) x 490(W) x 228(D) mm
TBD
CE, FCC, UL60601-1,TUV
EN60601-1
Mechanical drawing
UNiT : mm
o
0 0
~+90
F l e x i b i l i t y y
Features :
* IPS extra wide view angle TFT LCD technology.
* IPX1 Spilling proof Compliant.
* CE, FCC, TUV EN 60601-1, UL 60601-1 medical
certification available.
* Fashionable Design with Slim bezel.
* High contrast color TFT LCD display support
resolution up to SXGA 1280x1024.
* Built-in Medical grade power adapter.
* Advanced OSD control for picture quality adjustment.
* Optional height, swivel, Tilt, and Rotation adjustable Stand.
* Multi-Signal Inprts : VGA. DVI, Composite Video,
o
S-Video (Auto DetectionOF Input Signals).
* NTSC/PAL,Video Systmes Compatible
* Support DDC1/2B for Plug & Play Compatibility.
Optional Accessories :
* 3M Capacitive Touch Sensor
* ELO/3M 5 wire Resistive Touch Sensor available
* Anti-Glare Tempered Protection glass
* 2 Watts internal Speakers
* Height Adjustable Stand Base
Ordering Information :
* MA19BH-AA
* MA19BH-AB
F )
* MA19BH-AE
* MA19BH-GB
* MA19BH-GE
I/O Ports
AC in
Front Side
MA19BH AA MA19BH-AA MA19BH AA
VGA
VGA, DVI-D
VGA, DVI-D, Video, S-Video, Audio
VGA, DVI-D, Hight Adjustable Stand
VGA, DVI-D, Video, S-Video, Audio,
Hight Adjustable Stand
Touch Audio in DVI-D
Back Side
VGA
