GVision MD15PX-L Specifications

15" Color TFT LCD Monitor
Medical Application
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal connector Analog
Video-in
Scan Frequency
Video System
Key Control
Touch Panel
Speakers Out (watts)(R/L)
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power Adapter
Power Consumption
Dimensions Landscape
Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s F l e x i b i l i t y
MD15PX-LA
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (Typical )
2
250 Cd/m (Typical )
16 ms
16,777,216 colors
304.1 (H) x 228.1 (V)
120 (H) x 100 (V)
2 CCFLs
30,000 hrs
o
Tilt Down: 0
o
Tilt Up: +36
Analogue VGA
D-sub 15 pin (VGA)
RCA jack, S-Video (Option)
60/70/72/75 Hz
NTSC/PAL
Power on/off with LED, Menu,
Select, Adjustment (+, - )
Resistive/Capacitive RS-232
or USB (Option)
2W / per channel driver(Option)
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48 watts
390(H) x 406(W) x 195(D) mm
450(H) x 482(W) x 263(D) mm
5.3 Kg
CE, FCC, UL60601-1,TUV
EN60601-1
Mechanical drawing
MD15PX-LA MD15PX LA MD15PX LA
y
Features :
* CE, FCC, TUV EN 60601-1, UL 60601-1 medical
certification available.
* High contrast color TFT LCD display support resolution
up to XGA 1024x768.
* Universal Medical grade power adapter.
* Multi-Signal Inprts : VGA, Composite Video,
S-Video (Auto DetectionOF Input Signals).
* Composite Video Systmes PAL, NTSC, SECAM
compatible.
* Support DDC1/2B for Plug & Play Compatibility.
* Advanced OSD control for picture quality adjustment.
Optional Accessories :
* 3M Capacitive Touch Sensor
* ELO/3M 5 wire Resistive Touch Sensor available
* Anti-Glare Tempered Protection glass
* 2 Watts internal Speakers
Ordering Information :
* MD15PX-LA VGA
* MD15PX-LE VGA, DVI-D, Video, S-Video, Audio
I/O Ports
Audio VGA Touch AC in
