GVision K30AC-C Specifications

3 0 " C h a s s i s T F T L C D M o n i t o r
Industrial Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration g
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNOT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
K30AC-CE
29.53" TFT active matrix panel
0.5025(H) x 0.5025 (V) mm
WXGA 1280 x 768
500:1 (typical)
2
500 cd/m (typical)
25 ms (typical)
16.7 M
643.20(H) x 385.92(V)
170 (H) x 170 (V)
CCFL x 16
50,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
DVI-D
RCA , S-video , Y.Cb.Cr
H. scan 31 ~ 91KHz,
V. scan 60 ~ 85Hz
N/A
N/A
N/A
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o
0 C-50 C (32oF-122oF)
20%-80% (no condensation)
To 10,000 feet
o o
-20 C-60 C ( -4oF-140oF )
10%-90% ( no condensation )
AC 100~240V , 50~60Hz
180W
VESA DPMS Standard
709.6 x 459.6 x 130 mm
890 x 640 x 310 mm
26 Kg
C-UL, FCC, CE
Mechanical drawing
Front Side
K30AC CE K30AC CE K30AC-CE
Features :
* Stable aluminum housing for public display.
* High contrast color TFT LCD open frame display support
resolution up to WXGA 1280x768. Compatible with IBM
VGA, VESA standards.
* Multi-signals: VGA, DVI, Composite video, S-Video.
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Reserved OSD buttons at the rear cabinet.
* IR remote control available.
* Optional multiple mounting.
* Built - in power.
Optional Accessories :
* Anti - glare tempered glass
Ordering Information :
* K30AC - CE VGA + DVI + Video-in
I/O Ports :
Power AC-in VGA
S-Video Video Audio R/L (Video)
Video-out
DVI Audio-in
Cr Cb Y Audio R/L
(YCbCr)
Back Side
