- Page 1 WWW.GVISION-USA.COM K-SERIES USER’S MANUAL (8” TO 15”) KIOSK TOUCHSCREEN MONITOR GVISION USA, INC 30398 Esperanza, Rancho Santa Margarita CA 92688 / 949.586.3338 / info@gvision-usa.com...
- Page 2 CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this equipment, please contact GVISION. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located.
- Page 3 Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 4: Table Of Contents
6.3 I/O Port…………………………………………………………………………………………………………….13 6.3.1 K08AS……………………………………………………………………………………………………….13 6.3.2 K15TX……………………………………………………………………………………………………….13 6.4 OSD Control Options…………………………………………………………………………………………...13 Screen Adjustment…………………………………………………………………………………..…………...…...14 Touch Installation…………………………………………………………………………………..…………...…..16 Trouble Shooting…………………………………………………………………………………..…………...…..17 10. Display Modes…………………………………………………………………………………..…………...…...18 10.1 K08AS……………………………………………………………………………………………………………..18 10.2 K15TX……………………………………………………………………………………………………………...18 11. Specification…………………………………………………………………………………..…………...…....19 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 5: Vesa Mounting Installation
(ref. Image 3). Please refer to user’s manual of UL listed wall mount bracket for wall mount installation. Image 1 Image 2 Image 3 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 6: 17"/19" Monitor Vesa Mounting
(ref. Image 3). Please refer to user’s manual of UL listed wall mount bracket for wall mount installation. Image 1 Image 2 Image 3 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 7: Fcc Statement
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 8: Weee Statement
Pro další informace o recyklaci kontaktujte místní recyklační středisko nebo místo nákupu výrobku. Svým postojem k recyklaci přispějete k lepší budoucnosti na Zemi a ke kvalitnějším životním podmínkám pro budoucí generace. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 9 你的回收行为，将为地球带来更美好的将来，为后代子孙创造更优质的生活环境 ◦ リサイクルに関する重要な情報 このごみ入れの警告標示は、物体を一般廃棄物として廃棄できないことを示しています。地方自治 体の規制に従い、居住する国または地域の廃棄物リサイクルおよび収集システムに従って廃棄を実 行してください。リサイクルの詳細については、地域の認可されたリサイクルセンターまたは購入 店にお問い合わせください。 お客様のリサイクルに対する態度は地球の未来、また後の世代の生活環境の向上をもたらすものと な るはずです。 Green MarkはJ-Mossに合致したと表す(JIS C 0950電, 電子の機械の特定的な化学の物質 は含有して方法を表す) 。 J- Mossの特定的な化学の物質の(鉛 水銀, カドミウム, 六つの値段クロム PBB, PBDE), その含有量きわめてになる低い 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 10: Japan Rohs Statement
ジュ-ル 液状結晶のデ Ο Ο Ο Ο スク ぶつかってモ ジュ-ルを訴え Ο Ο Ο Ο Ο た 1. 「Ο」は計算されたこういう物質のパ-セントの内容が參考のパ-セントの内容を越え たなかったと表明したと気を配りました。 2. が「免除し」たことを注意して計算されたことを表すこういう物質のパ-セントは合 致して項目を免除します。 X : 免除した 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 11: Introduction
RCA / S-Video signal cable for video-in function (option) Audio cable (option) Power adapter / AC power cord (option) Touch screen CD driver (option) 4 pieces M4x10mm washer screws (option) 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 12: Monitor Controls
Press “▼” button and then press Power switch together to freeze all function keys. Press “▼” button and then press Power switch together to unlock the keys. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 13: I/O Port
6.4 OSD Control Options Pressing “-” button once opens the small Input Select icon. PC ANALOG PC DIGITAL (Optional) VIDEO (Optional) S-VIDEO (Optional) EXIT 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 14: Screen Adjustment
Select one display pattern from your computer. PHASE Use “+” and “-” buttons on the LCD monitor to decrease the horizontal interference to get the optimal display 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 15 Adjust the sharpness using + or - buttons to set up (For the model with Video input only) SATURATION Adjust the video image color saturation using + or - buttons to set up 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 16: Touch Installation
1) Pasting the viscose side of the sponge on the front housing. 2) Let the mylar side of the sponge to contact touch screen. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 17: Trouble Shooting
LCD monitor. WARNING: Do not disassemble the monitor. Contact your dealer if needed. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 18: Display Modes
8.4” 800X600 SVGA 48.077 72.188 50.000 800X600 SVGA 46.875 75.000 49.500 1024X768 48.36 60.00 65.00 15” 1024X768 60.00 70.00 75.00 1024X7684 79.98 75.00 78.75 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 19: K08As
12V DC / 3.3A 12V DC / 3A TEMPERATURE Operating 0~40°C 0~40°C VESA™ Mount Size 75x75mm 75x75mm Specifications subject to change without any notice 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 20 WWW.GVISION-USA.COM NOTE: For quality performance. Please refer the graph below for the corresponding of temperature and humidity. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
