GVision P15PX-L Specifications

1 5 " T F T L C D M o n i t o r 1 5 " T F T L C D M o n i t o r
POS Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal Connector Analog
Digital
Scan Frequency
Audio System
USB HUB
Touch Panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions ( W x H x D )
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
P15PX-LA
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
304.1(H) x 228.1(V)
120 (H) x 100 (V)
CCFL x 2
40,000(hr)
o o
Tilt down: -5 , Tilt up: +15
Analogue VGA
D-sub 15 pin (VGA)
N/A
H. scan 31~60KHz,
V. scan 60~75Hz
1W/per channel driver (option)
N/A
Resistive/Capacitive - RS232
or USB A type (option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
AC Input, Universal
100 ~ 240V
36W
VESA DPMS standard
390 x 406 x 195 mm
450 x 482 x 263 mm
5.3 Kg
C-UL, FCC, CE
Mechanical drawing
P15PX-L
P15PX LA P15PX-LA
Features :
* High contrast color TFT LCD display supports resolution
up to XGA 1024x768. Compatible with IBM VGA, VESA
standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Built-in power.
* Built-in audio system.
* Optional stable photo stand excellent for touch solution.
* Optional black & white housing.
* Optional touch solutions.
* Optional VESA mounting.
* Hot key for AUTO adjustment.
Optional Accessories :
* 3M 5 Wire resistive touch panel
* 3M Capacitive Touch Panel
* ELO 5 Wire resistive touch panel
* Anti-Glare tempered glass.
* Customized touch solutions acceptable.
* Speaker
* External power adaptor
* Photo stand
Ordering Information :
* P15PX-LA VGA + speakers
* P15PX-JA VGA + speakers +photo stand
* P15KX-LA VGA only
* P15KX-JA VGA + photo stand
I/O Ports
Audio in VGA Touch AC in
P15PX-J
Front Side Back Side
