Dancover GH152080 Manual

2,45x3,04x2,1m
Hide thumbs

Advertisement

Quick Links

Download this manual
Manual
for
Greenhouse
2,45x3,04x2,1m
28-11-2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the GH152080 and is the answer not in the manual?

Questions and answers

Related Manuals for Dancover GH152080

Summary of Contents for Dancover GH152080

  • Page 1 Manual Greenhouse 2,45x3,04x2,1m 28-11-2019...
  • Page 2 Assembly Instructions PRODUCT SIZE(LxWxH):304X245X210CM PLEASE READ CAREFULLY BEFORE ASSEMBLY...
  • Page 3 CONTENTS...
  • Page 4 Safety Warning & Advice KEEP WORKING AREA CLEAN AND DRY A cluttered, damp or wet working area may cause injuries. PREPARE A FLAT AND LEVEL BASE Make sure your greenhouse is located on a flat and level surface. DO NOT INSTALL THE GREENHOUSE ON A WINDY DAY OR IN AN AREA SUBJECT TO HIGH WINDS Although this greenhouse is designed to withstand greater wind loads than many other greenhouses, do not install it in on a windy day or in an area which is subject to high winds.
  • Page 5 PART NO QTY Base Assembly M6X10 M4.2X16 16*S01 A1 B1 4*S01 Fixing the greenhouse to the base is recommended. It is best to do this at the end, after the greenhouse has been fully assembled.
  • Page 6 Use a powered screwdriver to fix the self-tapping screws (Z01) through the cills (L08A, L10 and L13) and base plinth (A1 and B1). The screws should be evenly spaced to ensure a neat appearance. The recommended spacing of the screws is 238mm. You can mark the painted surfaces with a pencil. L08A L08A L08A...
  • Page 7 PART PART PART L01A L01B L03B L03C L04A PART L04B L02A J02R L05B L02B J02L L02C L02D 48+2 M6X10 48+2 L03B PART M4X10 L01A M4X10 L08A 182+10 L01B M4.2X16 L03B L12A L04A L04B L04C L05A PART PART PART PC/Glass...
  • Page 8 PART NO QTY Vent Assembly M4.2X16 M4X10 2*S02 Slide 2 bolts (S02) into the bolt channel (L21) and fix the handle (W06) in the middle 4*Z01...
  • Page 9 PART NO QTY Door Assembly M4.2X16 16*Z01...
  • Page 10 PART NO QTY L04A L04B L01A L01A L01A L04B L04A M4.2X16 1. Lay out the glazing bars (2 x L01A, L04A and L04B) and the cill (L10). Ensure that the cill upstand is on the inside and that L01A is the correct way round. 2.
  • Page 11 PART NO QTY L05B M4.2X16 L05B L05B M6X10 L01A L01A L04A L04B L05B 1. Fix 1 x L05B to L01A and L04A and 1 x L05B to L04B and L01A with the self-tapping screws (Z01) using a powered screwdriver. Ensure that L05B is fixed at a right angle (90 degrees) to the glazing bars (2 x L01A, L04A and L04B).
  • Page 12 PART NO QTY L03B L03C M6X10 L03B L03B 2*S01 L03B L05B 1. Slide the lower glazing panels (Y2) into position. 2. Slide 2 bolts (S01) into the inside L03B bolt channel and fix L03B to L05B. 3. Make a pencil mark on L11 at a distance of 594mm from the right. Fix the plate (W04) using the extra S01 bolt placed in the bolt channel earlier.
  • Page 13 PART NO QTY L01B Front Wall L01B M4.2X16 L01B Fix 1 x L01B to L01A and L04A and 1 x L01B to L04B and L01A using the W01 angled plates fixed with self-tapping screws (Z01) using a powered L01A L01A L04A L04B screwdriver.
  • Page 14 PART NO QTY L04A L04B L04C L01A L01A L01A L04B L04A L04C M4.2X16 1. Lay out the glazing bars (2 x L01A, L04A, L04B and L04C) and the cill (L13). Ensure that the cill upstand is on the inside and that L01A is the correct way round. 2.
  • Page 15 PART NO QTY L05A M4.2X16 L05A L05A L01A L04C L04A L01B L01A 1. Fix the horizontal brace (L05A) to the glazing bars (2 x L01A, L04A, L04B and L04C) with the self-tapping screws (Z01) using a powered screwdriver. Ensure that L05A is fixed at a right angle (90 degrees) to the glazing bars.
  • Page 16 PART NO QTY L03B 2*S01 L03B M6X10 L03B L03B L05A 1. Slide 2 bolts (S01) into the inside L03B bolt channel and fix L03B to L05A. 2. Slide the higher glazing panels (Y3, Y5, Y8 and Y13) into position.
  • Page 17 PART NO QTY L01B Rear Wall M4.2X16 L01B L01B 1. Fix 1 x L01B to L01A and L04A and 1 x L01B to L04B and L01A using the W01 angled plates fixed with self-tapping screws (Z01) using a powered screwdriver. The inside of the glazing bars feature guide lines which indicate the correct screw positions (see detail drawings below).
  • Page 18 PART NO QTY L08A L01A M6X10 Rear 3*S01 Front L08A L08A 1. Slide 3 bolts (S01) into each L01A bolt channel (2 to be used later). 2. Bolt 2 x L08A cills to L01A using S01 bolts L01A L01A Screw L08A Position...
  • Page 19 PART NO QTY M6X10 L01B L01B L01A L01A Slide 3 bolts (S01) into each L01B bolt channel (2 to be used later). Bolt 2 x L07 eaves to L01A and L01B using S01 bolts L01B L01B L01B 3*S01 L01A L01A...
  • Page 20 PART NO QTY L02A M4.2X16 L02A Fix the glazing bars (L02A) to the cills (L08A) and the eaves (L07) with the self-tapping screws (Z01) using a powered screwdriver. The inside of the glazing bars feature guide lines which indicate the correct screw positions (see detail drawings below). Be careful to ensure that the screws are in the correct position (see detail drawings below).
  • Page 21 PART NO QTY L12A M4.2X16 L12A Fix 2 x L12A to the glazing bars at a height of 615mm. Bolt L12A to L01A using the extra S01 bolt placed in the bolt channel earlier. Fix the L12A to L02A with the self-tapping screws (Z01) using a powered screwdriver.
  • Page 22 PART NO QTY Bolt the ridge (L06) to 4 x L01B using the extra S01 bolts placed in the bolt channels earlier. Please note, if extra bolts were not placed in the bolt channel earlier L01B must be unbolted at one end and moved enough to squeeze the bolts in.
  • Page 23 PART NO QTY L02C L02D L02B L02B L02B M4.2X16 L02B L02B L02B L02D Fix the glazing bars (L02B and L02D) to the eaves (L07) and the ridge (L06) with the self- tapping screws (Z01) using a powered screwdriver. The inside of the glazing bars feature guide lines which indicate the correct screw positions (see detail drawings below).
  • Page 24 Slide the roof vents into position along the ridge (L06). The top of the roof vent locates in a groove in the ridge (L06). Please note that the glazing bars obstruct the passage of the roof vents, which must be in position before the last of the glazing bars are fixed.
  • Page 25 PART NO QTY L02C L02B M4.2X16 L02B L02C After the roof vents are in position, fix the last of the glazing bars (L02C) to the eaves (L07) and the ridge (L06) with the self-tapping screws (Z01) using a powered screwdriver. The inside of the glazing bars feature guide lines which indicate the correct screw positions (see detail drawings below).
  • Page 26 PART NO QTY L03B M6X10 L03B 1. Slide 4 bolts (S01) into the bolt channel on the inside of L03B horizontal framing. 2. Use 2 of the bolts (S01) to bolt L03B horizontal framing to the glazing bars. 3. Use the other 2 bolts (S01) to bolt the window pins (W08) to L03B. L02C L02D 4*S01...
  • Page 27 PART NO QTY L12A M4.2X16 1. Make a pencil mark on the end roof glazing bars (L01B) at a height of 766mm from the bottom. 2. Bolt 2 x L12A at each end to 4 x L01B using the extra S01 bolts placed in the bolt channels earlier.
  • Page 28 PART NO QTY Panel Assembly...
  • Page 29 PART NO QTY After the glazing panels are in position, slide the gutter (L09) into position along the eaves (L07). The gutter (L09) locates in a groove in the eaves (L07). If required use a mallet.
  • Page 30 PART NO QTY 1. Bolt the door support rail (L14) to the horizontal framing (L11) using 3 extra S01 bolts placed in the bolt channels earlier. Please note, if extra bolts were not placed in the bolt channel earlier L01A must be unbolted at one end and moved enough to squeeze the bolts in. 2.
  • Page 31 left door right door left door right door...
  • Page 32 PART NO QTY M4.2X16 1. Adjust the door until it moves smoothly 2. Fix L14 to the end roof glazing bar (L01B) with the self-tapping screws (Z01) using a powered screwdriver. The inside of the glazing bars feature guide lines which indicate the correct screw positions (see detail drawings below).
  • Page 33 PART NO QTY J02R J02L M4.2X16 Fix the cover caps (J01, J03 and J02R/L) carefully with the self-tapping screws (Z01). Be careful to ensure that the screws are driven in straight and in the correct position (see detail drawings below). 2*Z01 2*Z01 L01A...
  • Page 34 Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: 70 26 76 20 Spain: 911 436 828 denmark@dancover.com espana@dancover.com UK: 020 8099 7570 Italy: 02 479 21 198 uk@dancover.com...
