Page 3
Dear customer / dear garden friend, We congratulate you on purchasing a greenhouse. You have chosen a high quality and stable greenhouse. Please read the assembly instructions first. Follow this step by step! Storage / keeping Store protected - Please store all components in a dry place and protected from direct sunlight! Parts list / packing list Before you start to assemble the greenhouse, please use this description (material list) to...
Page 4
The construction of the greenhouse must be carried out by at least two people! Work with safe, handcrafted tools. Always work with gloves (risk of injury, risk of cuts) This symbol describes the manual work, e.g. the assembly of components You need the following tools to set up: ...
Page 5
Frame List of material: Width: 9,70m Lenght: 16,00m Note: The number of items in this material list corresponds to a greenhouse length of 16.00 m. If the greenhouse length is longer/shorter, the individual items will be adjusted accordingly! See also delivery note! Qty.
Page 6
1.26 18,00 13997 T-head bolts 8x80 1.27 7,00 9470 Spacer 1.28 2,00 20024 Rep-Tape Gable Qty. Part-No. Designation 2,00 9044 Gable 970ST with top part 6,00 13021 Twin wall plate (4 x 2,10m x 4,20m; 4 x 1,05m x 3,50m) 2,84 13022 H-Profile (4 x 3,50m)
Page 7
Side ventilation Qty. Part-No. Designation 1,82 13021 Twin wall plate (4 x 2,10m x 2,20m, 2 x 1,00 x 2,20m) 1,37 13022 H-Profile (2 x 2,20m) Cross tube 1.9m with 2 holes 6,00 9291 12,00 19004 Clamps 2 " Screw 8x40 12,00 14004 16,00 13002 Film: 10m transparent, divided for side ventilation...
Page 8
Foundation of your greenhouse The stable and robust construction of the greenhouses allows them to be installed directly on a level, pre-compacted surface. The fastening is carried out with an earth anchor system and the film has to be buried. 1.0 Angle the base 1.1 Tension cords alongside 1.2 Measure diagonally - distances must be the same...
Page 9
2.0.0 Anchor / longitudinal tube 2.1.0 150 cm (200 cm) 9,70 m 9,73 m 2.1.1 Place the anchor along the cord - see for distance 2.1 20007 2.1.2 Push the longitudinal tubes through the eyelets of the anchor 9251 9252 9253 2.1.3 Connect the longitudinal pipes to the pipe sections.
Page 10
3.0.0 Arch assembling 3.1.0 3.1.1 Assemble left / right arch - using connector 54 9084 9412 3.1.2 Fix the arch left / right to connector with screw 4.8x19 NOTE: nut must point inward 3.1.3 9433 Mount connector, center Place a spacer between the pipe bend and the connector 9470 NOTE: The nut must point downwards Push the pipe clamp (2x left / 2x right of the connector) onto the...
Page 11
3.2.0 Arch assembling 3.2.1 Place cross brace and screw left / right 9225 14007 NOTE: nut must point inwards 3.3.0 Connector longitudinal tube left / right 3.3.1 Mount connector on the right 9433 14006 NOTE: The nut must point downwards 3.3.2 9433 Mount connector, left...
Page 12
3.4.0 Struts 3.4.1 Screw the strut into the bore of the pipe bend left / right 9233 14007 3.4.2 Bring struts and cross struts together at point A and screw together 14004...
Page 13
3.5.0 Struts (outside) 3.5.1 Screw strut on pipe clamp in point 1 left / right 9248 14005 3.5.2 Push pipe clamp left / right (2x each) for point 2 onto the frame 19004 3.5.3 Screw strut on pipe clamp in point 2 left / right 9248 14005...
Page 14
4.1.0 Set up the arch / frame 4.1.1 Set up the preassembled frame in field 2 - screw it to the 14008 longitudinal tube 5.97m NOTE: - The nut must point inwards 4.1.2 Push pipe clamp left / right (2x each) for bandage onto the frame 19004 NOTE: The clamp leg must point inwards 4.1.3...
Page 15
4.2.0 Longitudinal pipes NOTE - As soon as a frame is set up - mount the longitudinal tube 4.2.1 Mount the center tube 9432 14005 4.2.2 Mount the longitudinal pipe on the left 9432 14005 4.2.3 Mount the longitudinal tubes on the right 9432 14005 4.3.0...
Page 16
4.4.0 Aluminum clamping profile with double mount 4.4.1 Fasten the aluminum clamping profile (double mount) to the arch with 18021 hammer head screws - drill a hole in the arch 13997 NOTE: Position the profiles at a height of approx. 2.20 m 13997 4.4.2 Fasten the gable aluminum clamping profile with a pipe clamp 4.4.3 Connect the aluminum profile with the square connector...
Page 17
5.0.0 Gable assembly 5.1.0 Gable element 5.1.1 Assemble gable element left / right using connector 54 9041 NOTE: nut must point down 9412 14006 5.1.2 Mount connector, center 9434 Place spacer between pipe bend and connector 9470 NOTE: nut must point down 14009 5.1.3 Mount connector, right –...
Page 18
5.2.0 Upper part of the gable 5.2.1 9206 14101 5.2.2 Mount the pre-assembled upper part of the gable 14101 NOTE: Use existing screw holes for positioning...
Page 19
5.4.0 Running rail 5.4.1 Mount the running rail Note: distance between running rail and post must be 15mm 5.4.2 Mount the retaining plate in the middle 5.4.3 Mount lteble, diagonally right and left...
Page 20
5.5.0 Guide shoes 5.5.1 Mount guide shoe holder left / right 9429 5.5.2 Mount the left / right guide shoe 9443 5.6.0 Alu-profile 5.6.1 Lay the Alu-Profile (6m length) over the gable arch 18020 Lateral height approx. 1.7 m 5.6.2 Fastening - Self-drilling screw 4.8x19 at a distance of approx. 30cm 14101 NOTE: Profile direction = film pull...
Page 21
5.7.0 Gable assembly 5.7.1 Place twin-wall sheets and screw them together 13021 NOTE: Screws with sealing washer 14102 NOTE: Screw spacing approx. 30cm NOTE: Adapt the multi-skin sheets to the arch contour using a cutter knife H-Profile 13022 5.7.2 Connect the joint edge of the twin-wall sheet with the H-profile 13022 5.7.3 Foam adhesive tape - tape off the sharp edge of the twin-wall sheet as protection for the film...
Page 22
6.1.0 Rabbit catch NOTE: Only greenhouse with side ventilation 40cm 6.1.1 Dig a trench along the greenhouse - about 20cm wide and 20cm deep 13021 14102 6.1.2 Fix the wire tensioner with a self-drilling screw 2x 13022 6.1.3 Guide the wire around the frame tube at the other end of the greenhouse and fix it with a wire clamp 6.1.4 Pull the wire tight using the wire tensioner 13021...
Page 23
7.1.0 Side panel NOTE: Only for the version with side ventilation with hand crank gear / motor drive and telescopic rod 3,0m 7.1.1 Put on the web plate (1) and screw it on 13021 NOTE: Slide the web plate under the aluminum profile at the top 14102 NOTE: Screws with sealing washer NOTE: Screw spacing approx.
Page 24
7.2.0 Side panel NOTE: Only for version with side ventilation and hand crank gear / motor drive / telescopic rod 2,0m 7.2.1 Place / align multi-wall plate (1) and screw on 13021 NOTE: Slide the web plate under the aluminum profile at the top 14102 NOTE: Screws with sealing washer NOTE: Screw spacing approx.
Page 25
8.1.0 Film NOTE: prerequisite for the installation of the foil is calm and temperatures above 8 ° C! NOTE: Before installing the film, mask off sharp edges, screws, etc. so that the film is not damaged. 8.1.1 Pull the film over the frame from one long side - use a rope of the 13003 appropriate length NOTE: Knot the foil at the corner points with a rope as a pulling aid...
Page 26
8.2.0 Tengel plate 8.2.1 Tengel plate ST head piece (1) 9458 Note: screw on from the front with a self-drilling screw every 50cm 14101 8.2.2 Tengel plate ST middle piece left (2) 9456 Note: screw on from the front with a self-drilling screw every 50cm 14101 Note: Sheets must overlap - middle piece under head piece 8.2.3...
Page 27
8.3.0 Fan for double foil 20028 8.3.1 Cut a hole (Ø90mm) in the multi-skin sheet 8.3.2 Push the fan through the hole Secure the fan 8.3.3 with the counter plate (bayonet lock) 8.3.4 Place a 90 ° bend on the socket from the outside NOTE: Suction direction downwards 8.3.5...
Page 28
9.1.0 Doors 9090 9.1.1 Screw the trolleys into the holes provided 20003 14055 9.1.2 Hang the door on the track 20002 9.1.3 Place the door stop at the end of the track 20004 9.1.4 Mount the door handle 9541 9.2.0 Repeat steps 1.8.1 - 1.8.4 for the second door...
Page 29
10.1.0 Side slide 10.1.1 Place the winding tube connector between the winding tube and 9249 screw it together 9411 10.1.2 Place the winding tube lengthways next to the greenhouse 10.1.3 Wrap the foil with the seam in the aluminum profile 13013 NOTE: Align the film before wrapping it 10.1.4 Angle tube - lay on the open side of the foil...
Page 30
10.2.0 Drive (hand crank gear) 10.2.1 Place the hand crank gear on the gable - approx. 1.0 m high 20030 10.2.2 Transfer the hole spacing from the hand crank gear to the gable 10.2.3 Remove the hand crank gear and place 10.00 mm holes 10.2.4 Mount the hand crank gear in the bores 20030 14050...
Page 31
11.1.0 Mount the belt straps 11.1.1 The straps are attached to every other arch using self-tapping screws. 20139 NOTE: Belt strap at the top in the aluminum clamping profile and at 14102 the bottom in the middle of the rabbit catch 12.1.0 Side ventilation cover apron NOTE: Position - remote hand crank 12.1.1 Dig a trench along the greenhouse - approx.
