- Page 1 Manual Greenhouse Nursery 0,61x1,11x1,75m 15-11-2021...
- Page 2 Assembly Instructions PRODUCT SIZE(LxWxH): 61X111X175CM PLEASE READ CAREFULLY BEFORE ASSEMBLY...
- Page 3 PART PART PART PART L13A J118 L01A L01B L13B J119L D100 L01C D108 J119R L19A D117 L02A J120 L19B H78-1 H78-2 L18A L08A M6X10 L18B L08B M6X12 L03A L10A L14A L23A L22B Ø4X12 L21A L22A Ø4X12D M4.2X10 PART POLYCARBONATE PANEL PC/Glass Milky Film sheet...
- Page 4 PART Roof Vent Assembly L19A L19B L23A D108 Ø4X12D Ø4X12 L19A L19A L19B Fix L19A to L20 & L19B using Z15, then insert the panel Y10 into position. Fix another L19A, using Z15.
- Page 5 Fix L23A & L31 to the window as below, using D108 and Z15. (L23A & L31 are factory fitted as a part already) D108 L23A L23A D108 D108 L23A D108 Fix part A68 to L19B, using Z03.
- Page 6 PART L18B L18A L18B L18A L18A Ø4X12D Outside View Door Assembly L18B L18A L18A Fix L18A to L15&L18B using Z15,then put the panel Y11 L18B L18B into position. L18A L18A L18A L18A Fix another L18A to L15 &L18Busing Z15.
- Page 7 PART Shelves Assembly (4PCS) L22A Fix L21A (4PCS) to 2 * L22A as below, L21A using Z15. Ø4X12D L22A L21A L21A L22A L21A Insert panel Y7 into the channel of L22A. Attention: If glass is chosen, make sure the shelves should be put in a safe place to avoid damaging or falling off after assembly.
- Page 8 PART Main Frame Assembly L08A L02A L08B L02A L01B L10A L01A L01A L01B L01A L01B L02A M6X10 S35/M14 L08B L08A L08A L10A S35/M14 S35/M14 Fix the base and all the vertical elements using S35 & M14.
- Page 9 PART L03A L22B L03A L22B L22B Ø4X12D L03A M6X12 M6X10 L03A L22B L22B L22B 1. Fix L22B to L01A & L01B, using S35 & M14. 2. Slide S37 * 2 into the channel of L03A, and fix it onto L22B, using M15. L22B L22B L03A...
- Page 10 PART Put the panels into positions. L01C D100 M6X10 L01C L01C Fix L01C to L06, using D100 and S35/M14. L01C L01C D100 L01C...
- Page 11 Fix L07 to L01A & L01B, using S35 & M14. S35/M14 Fix the roof frame to L01A, L01B and L07, using plate D99 and S35 & M14.
- Page 12 PART Slide both Doors into the track as shown. Door L14A L13A L13B Door Side View from Top H78-1 H78-2 J118 J119L J119R J120 Ø4X12D M4.2X10 Door Ø4X12 Side View from Bottom J120 J119L/R L03A Secure L14A onto L03A using Z19. J118...
- Page 13 Fix L13A and L13B to L07 and L14A L10A using Z15. L13A L13B L13A L13A&L13B H78-1 H78-2 L18A Put the magnetic sticker H78 onto L18A and L13A & B at matching positions so that the door can close tightly. * Make sure the stickers don't cover the holes on L13A & B. L13A...
- Page 14 PART Window L23A M6X12 Roof Vent L23A D117 M6X10 Roof Vent Slide 2 * S37 into the channel of L31 to fix it to L06 using M15. L23A S35/M14 Loosen the existing Z15, and fix D117 bracket to L13A/B & L01A/B using the same Z15 and S35 & M14.
- Page 15 Head office: Dancover A/S For more information Lyngevej 16A, Nørre Herlev please visit: 3400 Hillerød www.dancovershop.com Denmark...
