GTO SW-3000XL Installation Manual

Single gate operator system
Hide thumbs Also See for SW-3000XL:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual , Installation Manual
Installation Manual
for the
WARNING
!
MOVING GATE
SINGLE Gate Operator System
FOR PROFESSIONAL INSTALLATION ONLY!
WARNING!
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and
safety instructions. Failure to follow installation and safety instructions can result
in hazards developing due to improper assembly. You agree to properly install this
product and that if you fail to do so GTO, Inc. shall in no event be liable for direct,
indirect, incidental, special or consequential damages or loss of profits whether
based in contract tort or any other legal theory during the course of the warranty
or at any time thereafter. The installer and/or user agree to assume responsibility
for all liability and use of this product releasing GTO, Inc. from any and all
liability. If you are not in agreement with this disclaimer or do not feel capable
of properly following all installation and safety instructions you may return this
product for full replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before
attempting to install and use this automatic gate operator. This gate operator
produces a high level of force. Stay clear of the unit while it is operating and
exercise caution at all times.
All automatic gate operators are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which regulates gate operator safety,
as established and made effective March 1, 2000, by Underwriters Laboratories Inc.
For more information on GTO/PRO's full line of automatic gate openers and access controls visit our website at www.gtopro.com
2007 GTO, Inc.
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-3000XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GTO SW-3000XL

Summary of Contents for GTO SW-3000XL

  • Page 1 You agree to properly install this product and that if you fail to do so GTO, Inc. shall in no event be liable for direct, indirect, incidental, special or consequential damages or loss of profits whether based in contract tort or any other legal theory during the course of the warranty or at any time thereafter.

  • Page 2: Conversion Chart

    Please record the product serial number (located on the right side of the control box), and the date and place of purchase in the spaces provided below. Refer to this information when calling GTO for service or assistance with your automatic gate operator. Serial Number ____________________ Date of Purchase ____________________ Remember to keep all receipts for proof of purchase.

  • Page 3: Table Of Contents

    Table of Contents Gate Operator Class Categories ------------------------------------------------------------inside cover Units and Standards Conversion Chart ---------------------------------------------------inside cover PLEASE READ THIS FIRST! -------------------------------------------------- Important Safety Instructions -------------------------------------------------- Disconnecting the Operator -----------------------------------------------------------page 1 Important Safety Instructions for the Consumer ------------------------------------page 2 Secondary Means of Protection Against Entrapment ------------------------------page 5 Required Safety Precautions for Gates -----------------------------------------------page 6 Warning Signs and Labels -------------------------------------------------------------page 7 Installation --------------------------------------------------------------------------...

  • Page 4: Please Read This First

    3000XL Operator will give you many years of reliable service. Please read the following information to ensure you have the correct system for your particular needs. This manual will enable you to properly install your GTO/PRO® 3000XL Automatic Gate Operator.

  • Page 5: Important Safety Instructions

    Because GTO automatic gate operators are only part of the total gate operating system, it is the responsibility of the consumer to ensure that the total system is safe for its intended use.

  • Page 6: Important Safety Instructions For The Consumer

    IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury and/or death, for which the manufacturer cannot be held responsible. When designing a system that will be entered from a highway or main thoroughfare, make sure the system is placed far enough from the road to prevent traffic congestion.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS Entrapment Zones for a proper Pull-To-Open installation: Zone 1 – leading edge of the gate and the fence post. Zone 2 – between the gate and the gate post. Zone 3 – the path of the gate. Zone 4 –...
  • Page 8 If any of these signs or warning decals become damaged, illegible or missing, replace them immediately. Contact GTO for free replacements. The gate is automatic and could move at any time, posing a serious risk of entrapment. No one should be in contact with the gate when it is moving or stationary.

  • Page 9: Secondary Means Of Protection Against Entrapment

    The GTO/PRO® 3000XL utilizes Type A, an inherent (i.e., built-in) entrapment sensing system as the primary type of entrapment protection. Also, the GTO/PRO® 3000XL has provisions for the connection of Type B2 protection to be used as the secondary type of entrapment protection, if desired.

  • Page 10: Required Safety Precautions For Gates

    (recommended, not included) Entrapment Protection GTO’s inherent obstruction settings, even when properly adjusted, may not be sensitive enough to prevent bodily injury in some circumstances. For this reason, safety devices such as safety edge sensors (or photoelectric sensors), which stop and reverse gate direction upon sensing an obstruction, are suggested for enhanced protection against entrapment.

  • Page 11: Warning Signs And Labels

    3. Pull operator away from front or rear mounts. Disconnect operator ONLY when the control box power switch is OFF and the gate is NOT moving. GTO, Inc. Tallahassee, Florida USA Product identification and manual operation instruction label (1) installed on right side of control box.

  • Page 12: Parts List

    Single Gate Operator Parts List Operator and Mounting Hardware Customer Support Card (1) BRACKET BOX - HB3000 Post Pivot Bracket (1) HARDWARE BAG - H101P 3/8" x 8" Bolt (4) 3/8" x 3" Bolt (2) 3/8" x 2" Bolt (1) 5/16"...

  • Page 13: Installation

    Single Gate Operator Parts List Control Box and Electrical Components GTO Transmitter (1) Battery (1) RB500 Transformer (1) RB570 3/8” Bit Drill 5/16” Bit Pliers Open End Wrenches Level Clamps Small, Medium, Large YOU MAY ALSO NEED THESE ITEMS BEFORE YOU BEGIN THE INSTALLATION (Some of these items can be found in the Accessory Catalog page 37): •...

  • Page 14: Technical Specifications

    • The system is powered by a 12 Vdc, 7.0 Ah, sealed, rechargeable acid battery. • Battery charge is maintained by a 120 Vac, 18 Vac output transformer rectified to 14.5 Vdc (40 VA) through the GTO con- trol board. Blade-style control board fuse is rated for 25 A.

  • Page 15: Installation Overview

    Installation Overview Pull-to-Open Gates (Gate Opens into the Property) The diagram shown below is an example of a pull-to-open installation on a chain link fence and single gate. Mounting the operator on a masonry column requires special procedures; see Column Installation Information on page 36 if you intend to mount the operator on a column.

  • Page 16: Installation Of The Mounting Hardware

    Installation of Mounting Hardware The position of the post bracket determines the leverage and efficiency of the operator. The post bracket position also sets the clearance between the operator and gate in the open and closed positions (minimum 2 inches for safety reasons). The curved design of the post bracket works well for installations on round and square fence posts.
  • Page 17 Determining the Mounting Position of the Post Bracket Assembly and the Gate Bracket Step 3 Insert the " x 2" bolt through the center hole of the post brackets and post pivot bracket as shown. Fasten a " lock washer, "...
  • Page 18 for minimum 2 inches of clearance between the gate and the operator in both the open and closed positions, as shown in the diagrams below. This clearance will give the operator the most efficient leverage point for opening and closing the gate and more importantly provides the least possible pinch area.
  • Page 19 Installing the Post Bracket Assembly and Gate Step 7 Mark reference points for bolt holes on the fence post through middle of bracket slots. Marking reference points in this manner allows room for adjustment when mounting the post bracket assembly and gate bracket. After marking your reference points, remove the operator and brackets from the fence and gate.

  • Page 20: Mounting The Operator

    Installation of the Closed Position Stop The GTO/PRO® 3000XL Gate Operator firmly holds the gate in the closed position using the positive stop plate. The positive stop helps stabilize the gate leaf in the closed position. To further enhance the stability and security of your gate, install the optional GTO/PRO®...

  • Page 21: Mounting The Control Box

    3 feet from an AC power source to prevent electrical interference. NOTE: The battery that came with your GTO/PRO® 3000XL MUST be placed horizontally battery with the terminals on the RIGHT. If an optional second battery is needed, both batteries must be placed vertically with terminals at the bottom.

  • Page 22: Connecting The Power Cable

    Connecting Opener Power Cable Step 1 Make sure the control box power switch is in the OFF position. The ON/OFF Switch is located on the bottom of the control box. Remove the control box cover and slide the battery into position with its terminals to the RIGHT (see illustration).

  • Page 23: Powering The System

    • All low voltage wire used with the GTO PRO® Gate Opener must be 16 gauge dual conductor, multi-stranded, direct burial wire (see page 20 and the Accessory Catalog). Do not run more than 1000 feet of wire.
  • Page 24 IMPORTANT INFORMATION ABOUT LOW VOLTAGE WIRE The only wire acceptable for use with GTO products is 16 gauge multi-stranded, low voltage, PVC sheathed wire. This particular gauge enables the transformer to provide an adequate charge through the control board to the battery at distances up to 1000 ft.
  • Page 25 Step 7 Plug the transformer into the electrical outlet. (Use of a surge protector with the transformer is strongly recommended.) NOTE: This is a class II indoor transformer. IMPORTANT: If using transformer outdoors be sure to enclose it in a weatherproof case. HINT: Keep a few mothballs in the control box to discourage insects from entering it and damaging the control board.

  • Page 26: Control Board Settings

    DIP Switches Main DIP Switch Settings (MODES) DIP Switch #1 - Soft Start/Stop ON - Soft start enabled (factory preset). OFF - Soft start disabled. The Soft Start/Stop feature slowly starts the gate as it begins to open and slows the gate as it comes to the closed position.

  • Page 27: Setting The Closed Position

    11. If the transmitter does not activate the gate operator you may have to reset the transmitter code (see pg 25). TURN CONTROL BOX ON Your GTO PRO® has two Limit Settings 1) OPEN Limit setting: (Gate in the OPEN POSITION / the limit is FACTORY SET and NOT ADJUSTABLE) The open limit setting is the fully open position.

  • Page 28: Obstruction Sensitivity

    Obstruction Sensitivity Potentiometer IMPORTANT: For safety reasons the obstruction setting or Stall Force on the GTO PRO® control board comes from the factory set at MIN (minimum). In many gate in- stallations this setting will need to be adjusted to overcome the weight and size of the gates.

  • Page 29: Setting Your Personal Transmitter Code

    Setting Your Personal Transmitter Code All GTO transmitters are set to a standard code at the factory and are ready to operate your GTO PRO® Gate Opener For your safety and security, however, we strongly recommend that you replace the factory setting with your own personal code.

  • Page 30: Installing The Receiver

    • Standard receiver cable length is 10 feet (receivers with a longer cable are available as special order items; call the GTO Sales Department). NEVER splice receiver cable! • Run the cable through PVC conduit to protect it from damage.

  • Page 31: Connecting Accessories

    Connecting Accessories Input Connections NOTE: • All control inputs are dry-contact, normally open, inputs. DO NOT apply external voltage sources to these inputs. • All inputs are connected with respect to COMMON terminal. • The status LED will blink once when its corresponding input is activated. COM: Circuit common (reference for all logic input) •...

  • Page 32: Wiring Accessories

    V – LOOP LOOP GTO/PRO Loop Detector LOOP GTO/PRO Push Button Control GTO/PRO Keypad CONTROL INPUTS SLAVE CABLE BLUE COM COM SLAVE INPUTS NOTE: Connections are for typical applications. There may be additional connection options for applications that are not illustrated here.

  • Page 33: Push To Open Installation

    Connecting Other Auxiliary Devices (Mag Locks, Sirens, Lights, etc.} • These 2 terminals are normally open 'dry-contact' (no voltage) relay ouput. • These 2 terminals are ON (shorted) whenever the gate is moving and OFF (opened) otherwise. • These 2 terminals maximum rating is 24Vdc, 1 Amp. Push to Open Installation Determining The Mounting Position of The Post Bracket Assembly...

  • Page 34: Setting Open Position Limits

    Push to Open Installation Step 3 With the gate in the fully closed position and the opener retracted, align the opener to the gate. Mark reference points for bolt holes on gate cross member through middle of gate bracket slots. The opener must be level. (Some vertical adjustment is possible by sliding the post bracket assembly up and down.) Drill gate bracket to cross member using (2) 3/8"...
  • Page 35 Step 3 With the gate in the desired open position PRESS & HOLD the “LEARN MAST LIMIT" button on the control board for 5 seconds. Step 4 Press the transmitter button and allow the gate to return to the closed position. YOUR GATE’S OPEN POSITION LIMIT IS NOW PROGRAMMED.

  • Page 36: Troubleshooting Guide

    Troubleshooting Guide If your gate opener does not function properly after it is installed, use this guide before calling the GTO Service Department. Generation 3 Audible Feedback Symptom Diagnosis 1 short beep upon Blown Fuse activation Low or Bad Battery...
  • Page 37 Symptom Diagnosis Status (clear) Cycle Terminal 1 blink Shorted Status (clear) Safety Terminal 2 blinks Shorted Status (clear) Exit Terminal 3 blinks Shorted Shadow Terminal Status (clear) Shorted 4 blinks Status (clear) Close Edge 5 blinks Terminal Shorted Status (clear) Open Edge 6 blinks Terminal Shorted...

  • Page 38: Repair Service

    1. First use the procedures found in the Troubleshooting Guide (see page 32). 2. If you are unable to solve the problem, call the GTO/PRO Service Department at (800) 543-1236, or (850) 575-4144. Refer to the serial number (located on the control box cover) and date of purchase when calling for assistance.
  • Page 39 Fax (850) 575-8950 • Web site: www.gtopro.com E-Mail: techsupport@gtoinc.com 3121 Hartsfield Road • Tallahassee, Florida, USA 32303 Telephone GTO Sales: 1-800-543-GATE (4283) or (850) 575-0176 • Fax (850) 580-8816 w w w . g t o p r o . c o m VOLTAGE RATINGS –...

  • Page 40: Column Installation Information

    Column Installation Information F THIS OPERATOR WILL BE USED WITH GATES THAT ARE MOUNTED ON MASONRY, BRICK, OR ROCK (etc.) COLUMNS: READ THE FOLLOWING CAREFULLY BEFORE PROCEEDING The simplest solution is to install the operator in a push-to-open configuration (requires Push-To-Open Bracket, see Accessory Catalog).

  • Page 41: Accessory Catalog

    ACCESSORIES Solar Panel (FM123), (FM122) The Solar Panel is a 10 watt solar powered battery charger for use with the all GTO/PRO DC gate operator systems. Particularly suited for remote installations, each Solar Panel comes with tubular steel support, mounting clips, wire connectors, and 8 ft. of low voltage wire (see Low Voltage Wire for additional wire).
  • Page 42 If you have a question about GTO/PRO accessories The contents of all material available on this installation manual are copyrighted by GTO, Inc. (“GTO”), unless otherwise indicated. All rights are reserved by GTO, and content may not be reproduced, downloaded, disseminated, published, or transferred in any form or by any means, except with the prior, written permission of GTO. Any reprinting of GTO publications is by permission only. Copyright GTO®, GTO/PRO®, Bulldog®...
