GTO SW-2002XL Installation Manual

Dual gate operator system
Hide thumbs Also See for SW-2002XL:
Table of Contents

Advertisement

Quick Links

Installation Manual
for the
®
1-800-543-GATE (4283) • www.gtopro.com
1-800-543-GATE (4283) • www.gtopro.com
DUAL Gate Operator System
FOR PROFESSIONAL INSTALLATION ONLY!
WARNING!
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and
safety instructions. Failure to follow installation and safety instructions can result
in hazards developing due to improper assembly. You agree to properly install this
product and that if you fail to do so GTO, Inc. shall in no event be liable for direct,
indirect, incidental, special or consequential damages or loss of profits whether
based in contract tort or any other legal theory during the course of the warranty
or at any time thereafter. The installer and/or user agree to assume responsibility
for all liability and use of this product releasing GTO, Inc. from any and all
liability. If you are not in agreement with this disclaimer or do not feel capable
of properly following all installation and safety instructions you may return this
product for full replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before
attempting to install and use this automatic gate operator. This gate operator
produces a high level of force. Stay clear of the unit while it is operating and
exercise caution at all times.
All automatic gate operators are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which regulates gate operator safety,
as established and made effective March 1, 2000, by Underwriters Laboratories Inc.
3121 Hartsfield Road • Tallahassee, Florida, USA 32303
Telephone GTO Sales: 1-800-543-GATE (4283) or (850) 575-0176 • Fax (850) 575-8912
or GTO Technical Service: 1-800-543-1236 or (850) 575-4144 • Fax (850)575-8950
www.gtopro.com­
2007 GTO, Inc.
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-2002XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GTO SW-2002XL

Summary of Contents for GTO SW-2002XL

  • Page 1 You agree to properly install this product and that if you fail to do so GTO, Inc. shall in no event be liable for direct, indirect, incidental, special or consequential damages or loss of profits whether based in contract tort or any other legal theory during the course of the warranty or at any time thereafter.

  • Page 2: Conversion Chart

    Please record the product serial number (located on the right hand side of the control box), and the date and place of purchase in the spaces provided below. Refer to this information when calling GTO for service or assistance with your automatic gate Serial Number ____________________ Date of Purchase ____________________ Remember to keep all receipts for proof of purchase.

  • Page 3: Table Of Contents

    Table of Contents Gate Opener Class Categories -------------------------------------------------------------inside cover Units and Standards Conversion Chart ---------------------------------------------------inside cover PLEASE READ THIS FIRST! -------------------------------------------------- Important Safety Instructions -------------------------------------------------- Disconnecting the Opener -------------------------------------------------------------page  Important Safety Instructions for the Consumer ------------------------------------page 2 Secondary Means of Protection Against Entrapment ------------------------------page 5 Required Safety Precautions for Gates -----------------------------------------------page 6 Warning Signs and Labels -------------------------------------------------------------page 7 Installation --------------------------------------------------------------------------...

  • Page 4: Please Read This First

    GTO/PRO® 2002XL Automatic Gate Operator. The GTO/PRO® 2002XL Operator is designed for installation on a pull-to-open dual leaf gate (gates that open into the property). By purchasing an accessory bracket, the GTO/PRO® 2002XL Operator can accommodate a push-to-open dual leaf gate (gates that open out from the property).

  • Page 5: Important Safety Instructions

    Because GTO automatic gate openers are only part of the total gate operating system, it is the responsibility of the consumer to ensure that the total system is safe for its intended use.

  • Page 6: Important Safety Instructions For The Consumer

    IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury and/or death, for which the manufacturer cannot be held responsible. When designing a system that will be entered from a highway or main thoroughfare, make sure the system is placed far enough from the road to prevent traffic congestion.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS Entrapment Zones for a proper Pull-To-Open installation: Zone  – area between two gates. Zone 2 – between the gate and the gate post. Zone 3 – the path of the gate. Zone 4 – the space between the gate in the open position and any object such as a wall, fence, tree, etc. Zone 5 –...
  • Page 8 If any of these signs or warning decals become damaged, illegible or missing, replace them immediately. Contact GTO for free replacements. The gate is automatic and could move at any time, posing a serious risk of entrapment. No one should be in contact with the gate when it is moving or stationary.

  • Page 9: Secondary Means Of Protection Against Entrapment

    The GTO/PRO® 2002XL utilizes Type A, an inherent (i.e., built-in) entrapment sensing system as the primary type of entrapment protection. Also, the GTO/PRO® 2002XL has provisions for the connection of Type B2 protection to be used as the secondary type of entrapment protection, if desired.

  • Page 10: Required Safety Precautions For Gates

    Entrapment Protection GTO’s inherent obstruction settings, even when properly adjusted, may not be sensitive enough to prevent bodily injury in some circumstances. For this reason, safety devices such as safety edge sensors (or photoelectric sensors), which stop and reverse gate direction upon sensing an obstruction, are suggested for enhanced protection against entrapment.

  • Page 11: Warning Signs And Labels

    3. Pull operator away from front or real mounts. Disconnect operator ONLY when the control box power switch is OFF and the gate is NOT moving. GTO, Inc. Tallahassee, Florida USA Product identification and manual operation instruction label (1) installed on right hand side of control box.

  • Page 12: Installation

    Dual Gate Opener Parts List Opener and Mounting Hardware...
  • Page 13 Dual Gate Opener Parts List Control Box and Electrical Components GTO Transmitter(1) Transformer (1) Tools Needed • Power Drill • Open End Wrenches — ", ", • " Drill Bit • Hacksaw or Heavy Duty Bolt Cutters • Small (Flat Bladed) Screwdriver •...

  • Page 14: Technical Specifications

    • The system is powered by a 2 Vdc, 7.0 Ah, sealed, rechargeable acid battery. • Battery charge is maintained by a 20 Vac, 8 Vac output transformer rectified to 4.5 Vdc (40 VA) through the GTO control board. One () blade-style control board fuse rated for 5 A.

  • Page 15: Preparation Of The Gate

    Installation Overview Pull-to-Open Gates (Gate Opens into the Property) The diagram shown below is an example of a pull-to-open installation on a chain link fence and dual gates. Furthermore, if you have push-to-open gates, you will need to purchase two (2) push-to-open brackets (see Accessory Catalog) to properly configure your system.

  • Page 16: Installation Of The Mounting Hardware

    Installation of Mounting Hardware The position of the post bracket determines the leverage and efficiency of the opener. The post bracket position also sets the clearance between the opener and gate in the open and closed positions (minimum 2 inches). The curved design of the post bracket works well for installations on round and square fence posts.
  • Page 17 Determining the Mounting Position of the Post Bracket Assembly and the Gate Bracket Step 3 IInsert the " x 2" bolt through the center hole of the post brackets and post pivot bracket as shown. Fasten a " lock washer, "...
  • Page 18 for minimum 2 inches of clearance between the gate and the opener in both the open and closed positions, as shown in the diagrams below. This clearance will give the opener the most efficient leverage point for opening and closing the gate and more importantly provides the least possible pinch area.
  • Page 19 Installing the Post Bracket Assembly and Gate Bracket Step 7 Mark reference points for bolt holes on the fence post through middle of bracket slots. Marking reference points in this manner allows room for adjustment when mounting the post bracket assembly and gate bracket. After marking your reference points, remove the opener and brackets from the fence and gate.
  • Page 20 Mounting the Master Arm Step 11 Attach the opener to the securely bolted post bracket assembly and gate bracket using clevis pins, bushings, and hairpin clips, or optional Pin Locks (see Accessory Catalog). Verify that the opener is level and adjust the post bracket assembly if necessary.

  • Page 21: Installation Of The Closed Position Stops

    The optional ground stop post is used to provide a secure point for the SLAVE gate to close against. If you will be using the GTO/PRO Horizontal Gate Lock accessory with your gate opener system, the closed position ground stop is REQUIRED, as shown in Steps 2 and 3 on the next page.
  • Page 22 Step 2 Install a low profile ground stop (not provided) beneath the SLAVE gate stop plate. The ground stop needs to be positioned near the end of the gate as shown in Illustration A and may be made of metal or concrete and should be firmly secured in the ground (we recommend setting it in concrete).
  • Page 23 3 feet from an AC power source to prevent electrical interference. NOTE: The battery that came with your GTO/PRO® 2002XL, MUST be placed in the top (horizontal) battery slot with the terminals on the RIGHT. The extra (vertical) battery slot is for an optional second battery.

  • Page 24: Mounting The Control Box

    Connecting Opener Power Cables MASTER Operator Arm Step 4 Insert the stripped power cable wires into the appropriate terminals on the MASTER CABLE terminal block. The green wire should be inserted into the GRN terminal, the white wire into WHT, the blue wire into BLU, brown wire into BRN, the orange wire into ORG, the red wire into RED, and the black wire into the BLK terminal.

  • Page 25: Powering The System

    (available at local electrical supply stores) must be used. • All low voltage wire used with the GTO/PRO multi-stranded, direct burial wire (see page 22 and the Accessory Catalog). Do not run more than 1000 feet of wire.

  • Page 26: Connecting The Transformer

    IMPORTANT INFORMATION ABOUT LOW VOLTAGE WIRE The only wire acceptable for use with GTO products is 16 gauge multi-stranded, low voltage, PVC sheathed wire. This particular gauge enables the transformer to provide an adequate charge through the control board to the battery at distances up to 1000 ft.
  • Page 27 Step 7 Plug the transformer into the electrical outlet. (Use of a surge protector with the transformer is strongly recommended.) HINT: Keep a few mothballs in the control box to discourage insects from entering it and damaging the control board. Step 6 Strip "...

  • Page 28: Control Board Settings

    DIP Switches Main DIP Switch Settings (MODES) DIP Switch #1 - Soft Start/Stop ON - Soft start enabled (factory preset). OFF - Soft start disabled. The Soft Start/Stop feature slowly starts the gate as it begins to open and slows the gate as it comes to the closed position.

  • Page 29: Setting Closed Position Limits

    Setting the Closed Position Limits for Pull to Open Applications TURN CONTROL BOX ON Your GTO/PRO® 2002XL has two Limit Settings ) OPEN Limit setting: (Gate in the OPEN POSITION / FACTORY SET NOT ADJUSTABLE) The open limit setting is the fully open position.

  • Page 30: Setting Your Personal Transmitter Code

    Follow Steps -7 again. Setting Your Personal Transmitter Code All GTO transmitters are set to a standard code at the factory and are ready to operate your GTO/PRO 2002XL® Gate Opener . For your safety and security, however, we strongly recommend that you replace the factory setting with your own ®...

  • Page 31: Stall Force

    • Standard receiver cable length is 0 feet (receivers with a longer cable are available as special order items; call the GTO Sales Department). NEVER splice receiver cable! • Run the cable through PVC conduit to protect it from damage.

  • Page 32: Connecting Additional Safety Devices

    PLEASE NOTE: Contact sensors are not included with the GTO/PRO® 2002XL. The GTO/PRO® 2002XL is equipped with built-in obstruction sensitivity. The opener is designed to stop and reverse the gate within 2 seconds when it comes in contact with an obstruction. However, obstruction sensitivity, although functioning properly, may not be sensitive enough to prevent bodily injury in some circumstances.
  • Page 33 If not installing a non-contact sensor skip to next section. PLEASE NOTE: Non-contact sensors are not included with the GTO/PRO® 2002XL. The GTO/PRO® 2002XL can also accept "Safety" input from normally open "dry-contact" output devices such as safety beams connected to the SAFETY input terminal.

  • Page 34: Connecting Accessories

    Connecting Accessories If not connecting accessories skip to next section. The GTO/PRO® 2002XL can accept NORMALLY OPEN, DRY-CONTACT accessories, such as; Push Button Entry Devices and Key Pads. Refer to the sensor manufacturer’s instructions for information about installing these devices on a vehicular gate.
  • Page 35 You do not use the lock board with this control board. GTO Lock Connection: Connect the red and black leads from the lock to the GTO LOCK terminal on the GTO/PRO® 2002XL control board. Connecting Other Auxiliary Devices (Mag Locks, Sirens, Lights, etc.}...

  • Page 36: Push To Open Installation

    Push to Open Installation Determining The Mounting Position of The Post Bracket Assembly Swinging gates shall not open into public access areas! A "Push-to-Open" gate opens out from the property. A Push-to-Open Bracket is required for this type of installation (see Accessory Catalog).

  • Page 37: Setting Open Position Limits

    Step 3 With the gate in the fully closed position and the opener retracted, swing the opener to the gate. Mark reference points for bolt holes on gate cross member through middle of gate bracket slots. The opener must be level. (Some vertical adjustment is possible by sliding the post bracket assembly up and down.) Drill gate bracket to cross member using (2) 3/8"...
  • Page 38 Step 3 Note which gate has reached the desired closed position (typically it's the slave gate), program the closed limit setting by pressing and holding the corresponding 'LEARN MAST LIMIT' or 'LEARN SLV LIMIT' button for 5 seconds. Step 4 Press the transmitter button and allow the gates to return to the closed position.

  • Page 39: Maintenance & Troubleshooting Guide

    Maintenance & Troubleshooting Guide If your gate opener does not function properly after it is installed, use this guide before calling the GTO Service Department. ‘PR03040-G3’ DIAGNOSTIC INDICATOR GUIDE This guide provides detail explanations of various alarm sound and led indicators for the new PRO3040- G3 board).
  • Page 40 Alarm: None ‘RECEIVER’ Led: blinking or OFF. • When the ‘RECEIVER’ led is blinking, the controller is receiving ‘GTO scheme’ 38 MHz signal from the receiver. This indicates that the transmitter and receiver are working properly. However, if the transmitter is not being pressed and the ‘RECEIVER’ led is blinking, this indicates that there is significant interference (i.e.
  • Page 41 3. Master arm running error indicators: Error Code ‘3’ Alarm: 3 beeps with 2 second pause. ‘STATUS’ Led: 3 blinks with 2 second pause. • No pulses are detected from the master arm rev counter input during the first -2 seconds of running the gate.

  • Page 42: Warranty And Repair Service

    . First use the procedures found in the Troubleshooting Guide (see page 35). 2. If you are unable to solve the problem, call the GTO/PRO Service Department at (800) 543-236, or (850) 575-444. Refer to the serial number (located on the right hand side of the control box) and date of purchase when calling for assistance.

  • Page 43: Accessory Catalog

    ACCESSORIES Solar Panel (FM123), (FM122) The Solar Panel is a 0 watt solar powered battery charger for use with the all GTO/PRO DC gate operator systems. Particularly suited for remote installations, each Solar Panel comes with tubular steel support, mounting clips, wire connectors, and 8 ft. of low voltage wire (see Low Voltage Wire for additional wire).
  • Page 44 If you have a question about GTO/PRO accessories The contents of all material available on this installation manual are copyrighted by GTO, Inc. (“GTO”), unless otherwise indicated. All rights are reserved by GTO, and content may not be reproduced, downloaded, disseminated, published, or transferred in any form or by any means, except with the prior, written permission of GTO. Any reprinting of GTO publications is by permission only. Copyright GTO®, GTO/PRO®, Bulldog®...
