GTO SW-3000XL Installation Manual

Dc series
Hide thumbs Also See for SW-3000XL:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual
Installation Manual
for installing the GTO/PRO SW-3200XL with the
GTO/PRO SW-3000XL in a dual application
DC-SERIES
®
DC-SERIES
®
FOR PROFESSIONAL INSTALLATION ONLY!
WARNING!
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and
safety instructions. Failure to follow installation and safety instructions can result
in hazards developing due to improper assembly. You agree to properly install this
product and that if you fail to do so GTO, Inc. shall in no event be liable for direct,
indirect, incidental, special or consequential damages or loss of profits whether
based in contract tort or any other legal theory during the course of the warranty
or at any time thereafter. The installer and/or user agree to assume responsibility
for all liability and use of this product releasing GTO, Inc. from any and all
liability. If you are not in agreement with this disclaimer or do not feel capable
of properly following all installation and safety instructions you may return this
product for full replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before
attempting to install and use this automatic gate operator. This gate operator
produces a high level of force. Stay clear of the unit while it is operating and
exercise caution at all times.
All automatic gate operators are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which regulates gate operator safety, as
established and made effective March 1, 2000, by Underwriters Laboratories Inc.
For more information on GTO/PRO's full line of automatic gate openers and access controls visit our website at www.gtopro.com
2007 GTO, Inc.
©
