SIPROTEC 5 Compact Terminals
Innovative terminals were developed for the SIPROTEC 5 Compact family. All terminals are individually remov-
able (Figure 2-10). This enables prewiring of the systems and simple device replacement without costly
rewiring.
[ph_SIP5Compact_remove_terminal, 1, --_--]
Figure 2-10
28
Removed Current Terminal Block, with a SIPROTEC 5 Device as an Example
