FA966800TX
Lowery Fireplace
For assistance with assembly contact:
Assembly Instructions
Southern Enterprises, Inc.
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
PO#:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA966800TX and is the answer not in the manual?

Questions and answers

Summary of Contents for Southern Enterprises FA966800TX

  • Page 1 FA966800TX Lowery Fireplace For assistance with assembly contact: Assembly Instructions Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#:...
  • Page 2 LOWERY FIREPLACE Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
  • Page 3 Quantity of 1 Firebox(sold in separate box) Quantity Quantity Quantity of 22 of 22 of 22 Cam Lock Wood Dowel 5/16” x1-1/2” Cam Bolt Quantity of 14 Screw∮5/32”x1” Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. Call customer service at 1-800-633-5096 Periodically apply furniture wax to renew for assistance, questions, or Parts.
  • Page 4 Loring Entryway Storage Bench Assembly Instructions Insert cam locks (C) into holes on small central pilasters (7L&7R) and front lower panel ( 6 ). Screw cam bolts (B) into holes on small central pilasters (7L&7R) and front upper Please do not over tighten cam bolts. panel ( 5 ).
  • Page 5 Insert cam locks (C) into holes on pre-assembled unit from figure2. Screw cam bolts (B) into holes on bottom panel (2). Attach pre-assembled unit from figure2 to bottom panel (2) by inserting wood dowels (B) and cam bolts (A) into corresponding holes until pre-assembled unit from figure2 and bottom panel (2) meet.
  • Page 6 Insert cam locks (C) into holes on pre-assembled unit from figure4. Screw cam bolts (B) into holes on top panel (1). .Attach pre-assembled unit from figure4 to top panel (1) by inserting wood dowels (A) and cam bolts (B) into corresponding holes until pre-assembled unit from figure4 and top panel (1) meet.
  • Page 7 Figure 7 Now your fireplace is ready to use.
  • Page 8 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
