- Page 1 Providence Convertible Fireplace Tower FA980700TX – New Mahogany FA980800TX – Antique White For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
- Page 2 Providence Convertible Fireplace Tower Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Of 2 Of 1 Back Top Panel Left Frame Quantity Quantity Of 1 Of 1 Right Frame Middle Shelf Panel Quantity Quantity Of 1 Of 1 Left Door Right Door Quantity Quantity Of 1 Of 1 Middle Shelf Panel Bottom Panel Quantity Quantity...
- Page 4 Providence Convertible Fireplace Tower Assembly Instructions Turn the middle shelf panel (5) over and use 2pcs round head screws (J) to connect magnet (H) to middle shelf panel (5) with Phillips screwdriver. Figure 1 Attach middle shelf panels (5) and (8) to the left frame (3) by inserting wood dowels (A).
- Page 5 Providence Convertible Fireplace Tower Assembly Instructions Attach legs (10) to assembled unit by rotating the legs (10) clockwise tightly with hand. Figure 3 Use legs (11) through bottom panel (9) to connect bottom panel (9) to the four legs (10) by rotating legs (11) clockwise tightly with hand.
- Page 6 Providence Convertible Fireplace Tower Assembly Instructions Use 6pcs flat head screws (D) to connect front top panel (1) to back top panel (2) via attached hinges. Tighten flat head screws (D) with Phillips screwdriver. Figure 5 Attach top panels (1) and (2) to assembled unit by inserting 4pcs wood dowels (A).
- Page 7 Attach the back panel (12) onto the back of the unit by using 16pcs screws (E). Figure 7 Use 8pcs screws (F) to connect door panels (6) and (7) to assembled unit with Phillips screwdriver. Figure 8...
- Page 8 Providence Convertible Fireplace Tower Assembly Instructions Place firebox (G) into the back of the unit. Figure 9 Attach wood holder (13) by inserting 2pcs flat head screws (I) into corresponding predrilled holes and tighten with Phillips screwdriver. Figure 10...
- Page 9 Providence Convertible Fireplace Tower Assembly Instructions Use screws (K) to connect brackets (L) to left frame (3) and right frame (4) as shown. Tighten screws (K) with Phillips screwdriver. Drill 1/4 inch pilot holes in near proximity of brackets (L) attached to the left frame (3) and right frame (4), then, tap the plastic anchor (N) into the wall.
- Page 10 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
