Cabrini Media Fireplace
FA934800TX -Black
FA934900TX -white
Assembly Instructions
Contact Southern Enterprises, Inc. at 1-800-633-5096.
For assistance with assembly, contact:
Customer Service 1-800-633-5096
PO#
Page 1
Southern Enterprises Inc.
service@seidal.com
www.seidal.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Southern Enterprises FA934900TX
Summary of Contents for Southern Enterprises FA934900TX
- Page 1 Support Questions: Contact Southern Enterprises, Inc. at 1-800-633-5096. For sales inquiries, contact Sylvane at 1-800-934-9194 or visit www.sylvane.com Cabrini Media Fireplace FA934800TX -Black FA934900TX -white For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 Cabrini Media Fireplace- Black Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 12 Of 28 of 4 Ø3*12mm Ø5/16”*1"L Flat Washer Screw For Back Long Flat Head Screw Quantity Quantity Quantity of 1 Of 2 Of 2 Ø5/32”*7/8"L Allen Wrench Knob Long Bolt Quantity Quantity Quantity of 4 of 24 of 8 Ø5/32”*5/8”L...
- Page 4 Cabrini Media Fireplace- Black Assembly Instructions Attach legs (8) to bottom panel (1) using long bolts (E) through spring washers (F) and flat washers (G). "Please do not over tighten cam bolts, stop when you feel them tighten" Tighten long bolts (E) with Allen wrench (J).
- Page 5 Insert cam locks (C) into holes on assembled unit. Screw cam bolts (A) into holes on lower top panel (4). Attach lower top panel (4) to assembled unit by inserting wood dowels (B) and cam bolts (A) into corresponding holes until panels meet.
- Page 6 Insert back panels (11L / 11R) into grooves in the back of assembled unit. Tighten screws (H) with Phillips screwdriver. Figure 5 To achieve uniform clearance around the door, you may need to adjust the door by tightening Use short flat head screws (N) to or loosening the two screws on the hinge itself.
- Page 7 Push firebox (14) into the back of the unit and insert long flat head screws (I) through wood holder (13) to lock tightly. Figure 7 Use screws (Q) to connect brackets (P) to lower top back (4) as shown. Tighten screws (Q) with Phillips screwdriver.
- Page 8 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 9 Support Questions: Contact Southern Enterprises, Inc. at 1-800-633-5096. For sales inquiries, contact Sylvane at 1-800-934-9194 or visit www.sylvane.com CAUTION The top shelf is intended for a flat screen television with a maximum overall width of 48” and supports up to 85 lb.
