Summary of Contents for Southern Enterprises FA939800TX
- Page 1 FA939800TX–CHERRY CRESTON MEDIA FIREPLACE MANTEL For assistance with assembly contact: ASSEMBLY INSTRUCTION Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Parts List
CRESTON MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. - Page 3 Quantity Quantity of 1 of 1 LEFT DIVIDED PANEL RIGHT DIVIDED PANEL Quantity Quantity of 1 of 2 BOTTOM PANEL DRAWER FRONT PANEL Quantity (10) Quantity of 2 of 4 DRAWER BACK PANEL DRAWER SHELF PANEL (11) Quantity (12) Quantity of 4 of 4 DRAWER UPPER SIDE PANEL...
- Page 4 CRESTON MEDIA FIREPLACE Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page Insert cam locks (C) into pre-drilled holes on left divided panel (5) & right divided panel (6).
- Page 5 CRESTON MEDIA FIREPLACE Assembly Instructions Insert cam locks (C) into pre-drilled holes on pre-assembled unit in figure 2 as shown. Screw cam bolt (A) into pre-drilled holes on bottom panel (7). Attach bottom panel (7) to pre-assemble parts in figure 2 by inserting wood dowel (B) &...
- Page 6 CRESTON MEDIA FIREPLACE Assembly Instructions Attach the three left drawer side panel (11),(12) & (13) on the drawer front panel (8) and drawer back panel (9) terrace . Secure by screw (F) and tightening with Phillips screwdriver (not included) as shown. Figure 5 Insert two pieces drawer shelf panel (10) to half assembled drawer parts...
- Page 7 CRESTON MEDIA FIREPLACE Assembly Instructions Attach the drawer pull (D) on the drawer front by bolt (E) as shown. Repeat the same way to assemble another drawer unit. Figure 7 Slide the drawer unit into the pre-assembled unit on the figure 4 by getting the drawer sliders well matched.
- Page 8 CRESTON MEDIA FIREPLACE Assembly Instructions Attach the side back panel (15) and upper back panel (14) on the pre-assembled unit by screw (G) as shown. Figure 9 Well put the fireplace (H) into the unit and avoid any scratch. Figure 10...
- Page 9 CRESTON MEDIA FIREPLACE Assembly Instructions Assemble the wood holder (16) on bottom panel by screw (F) as shown. figure 11 Now you can enjoy your new fireplace. Figure 12...
- Page 10 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 11 This unit contains a permanent warning sticker located on back panel. Do not allow children under 16 years old to move the cart. Model: FA939800TX–CHERRY CRESTON MEDIA FIREPLACE MANTEL...
