- Page 1 "Elkmont" Fireplace FA928100TX-Mahogany FA928200TX-Salem Antique Oak For assistance with assembly, contact: FA928300TX – Black Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
- Page 2 "ELKMONT" FIREPLACE Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 "ELKMONT" FIREPLACE Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 4 "ELKMONT" FIREPLACE” Assembly Instructions Insert Cam Bolts (A) and Wood Dowels (B) to the related holes on Left Front Panel (4) and Right Front Panel (5),then, insert Cam Locks (C) into related holes on Left Side Panel (2) and Right Side Panel (3). Connect Left Side Panel (2) to Left Front Panel (4), and Right Side Panel (5) to Right Front Panel (5) by insert the Wood Dowels (B) and...
- Page 5 "ELKMONT" FIREPLACE Assembly Instructions Insert Wood Dowels (B) into related holes on Base (7). Attach assembled unit from Figure 3 to base (7) by inserting Wood Dowels (B) into related holes. Figure 4 Secure assembled unit from Figure 3 onto the assembled unit from Figure 2 using Wood Screws (D).
- Page 6 "ELKMONT" FIREPLACE Assembly Instructions Gently slide the Insert through the rear of the mantle. Secure with Fixed Bars (11) and Wood Screws (D). Figure 7 Top panel support up to 85 lb. Figure 8...
- Page 7 Missing or damaged hardware and/or parts will be replaced free of charge. We do not sell parts. Southern Enterprises Inc. will provide replacement parts for only those items purchased within the last 9 months. If this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation to provide parts or replacement merchandise.
