"Antebellum" Media
Fireplace Mantle
FA930500TX- Black-Walnut 2 Finishes
FA930600TX- Antique White Finish
For assistance with assembly contact:
FA930800TX- Natural Oak Finish
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
Assembly Instructions
www.seidal.com
PO:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Southern Enterprises FA930500TX
Summary of Contents for Southern Enterprises FA930500TX
- Page 1 “Antebellum” Media Fireplace Mantle FA930500TX- Black-Walnut 2 Finishes FA930600TX- Antique White Finish For assistance with assembly contact: FA930800TX- Natural Oak Finish Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com...
- Page 2 “Antebellum” Media Fireplace Mantle Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware. Carefully study the hardware diagrams below.
- Page 3 “Antebellum” Media Fireplace Mantle Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware. Carefully study the hardware diagrams below.
- Page 4 “Antebellum” Media Fireplace Mantle Assembly Instructions Assembly Instructions: Wood may scratch easily. Be careful when assembling. Do not scratch. Step 1. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page.
- Page 5 “Antebellum” Media Fireplace Mantle Assembly Instructions Step 2. Attach Top Stretcher (H) to Middle Panels (F,G) Figure 3 Step 1. Insert Wood Dowels (1) into predrilled holes in Middle Panels (F,G) and Top stretcher(H). Step 2. Attach Horizontal Fixed Shelf (D) to the Middle Panels(F,G) and Top Stretcher(H) with Bolt(2) and Cam Lock(4).
- Page 6 “Antebellum” Media Fireplace Mantle Assembly Instructions Step 1. Insert the Wood Dowels (1) into predrilled holes in Side Panels (B,C). Step 2. Attach Top Panel (E) to the Side Panels (B,C) with Cam Lock (4). Quantity of 4 8mm x 30 mm Wood Dowel Quantity of 4...
- Page 7 “Antebellum” Media Fireplace Mantle Assembly Instructions Step 1. Insert Upper Back Panel (K) and Side Back Panel (L) into grooves on Side Panels (B,C), Top Panel(E) and Bottom Base(A) with Screw For Back(7) and tighten. Quantity of 42 3.5mm x 12mm Screw For Back Figure 8 Step 1.
- Page 8 “Antebellum” Media Fireplace Mantle Assembly Instructions Step 1. Attach Bracket (12) to the Top Panel (E) with Screw For Bracket (13). Step 2. Drill 3/8” pilot holes in near proximity of the Bracket(12) attached to the Top Panel(E) and tap the Plastic Anchor(14) into wall. Step 3.
- Page 9 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 10 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: FA930500TX & FA930600TX & FA930800TX “Antebellum” Media Fireplace Mantle Southern Enterprises, Inc...
