Model No. WLEX32709.0
Serial No.
Write the serial number in the
space above for reference.
Serial Number
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-866-699-3756
CALL TOLL-FREE:
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
All manuals and user guides at all-guides.com
Decal
USER'S MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo Pursuit CT 5.9
Summary of Contents for Weslo Pursuit CT 5.9
- Page 1 All manuals and user guides at all-guides.com www.weslo.com USER'S MANUAL Model No. WLEX32709.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE;...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise cycle before using your exercise cycle. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
Congratulations for selecting the new WESLO PRO after reading this manual, please see the front cover PURSUIT CT 5.9 exercise cycle. Cycling is one of the of this manual. To help us assist you, note the product most effective exercises for increasing cardiovascular... -
Page 5: Assembly
All manuals and user guides at all-guides.com ASSEMBLY To hire an authorized service technician to assemble the exercise cycle, call 1-800-445-2480. Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack- ing materials. - Page 6 All manuals and user guides at all-guides.com To make assembly easier, read the information on page 5 before you begin assembling the exercise cycle. With the help of another person, lift the Frame (1) and place a packing insert (not shown) under the Frame.
- Page 7 All manuals and user guides at all-guides.com 3. Identify the Right and Left Stabilizer Covers (12, 13), which are marked with “R” and “L” stickers. Attach each Stabilizer Cover (12, 13) to the Rear Stabilizer (2) with two M4 x 16mm Screws (62).
- Page 8 All manuals and user guides at all-guides.com 5. Tip: Avoid pinching the Wire Harness (40) Wire Tie during this step. Have another person hold the Upright (4) and the Top Shield (14) near the Frame (1). Locate the wire tie in the Upright and the Wire Harness (40) in the Frame.
- Page 9 All manuals and user guides at all-guides.com 7. The Console (5) can use four 1.5V “D” batteries (not included); alkaline batteries are recom- mended. IMPORTANT: If the Console has been exposed to cold temperatures, allow it Battery to warm to room temperature before insert- Covers ing batteries.
- Page 10 All manuals and user guides at all-guides.com 9. Slide the Bottom Handlebar Cover (55) upward into the back of the Console (5) and around the Handlebar (28) as shown. Attach the Bottom Handlebar Cover (55) to the Handlebar (28) with two M4 x 16mm Screws (62).
- Page 11 All manuals and user guides at all-guides.com 11. Tip: Avoid pinching the Pulse Wire (not shown) during this step. Attach the Backrest (8) to the Seat Carriage (6) with two M6 x 18mm Patch Screws (59) and two M6 x 42mm Patch Screws (60). See step 10.
- Page 12 All manuals and user guides at all-guides.com 13. Attach the Pulse Bar Cover (15) to the Seat Carriage (6) with two M4 x 16mm Screws (62). 14. Plug the Pulse Wire (38) into the Pulse Receptacle (39) on the underside of the Frame (1).
-
Page 13: How To Use The Exercise Cycle
All manuals and user guides at all-guides.com HOW TO USE THE EXERCISE CYCLE HOW TO ADJUST THE PEDAL STRAPS HOW TO MOVE THE EXERCISE CYCLE To adjust the pedal To move the exercise cycle, lift the rear stabilizer until straps, first pull the the exercise cycle can be moved on the front wheels. - Page 14 All manuals and user guides at all-guides.com CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even connect your MP3 player or CD player to the consoleʼs sound system and listen to your The advanced console offers an array of features favorite workout music or audio books while you designed to make your workouts more effective and exercise.
- Page 15 All manuals and user guides at all-guides.com HOW TO USE THE MANUAL MODE The lower left corner of the display will show your pedaling speed, in miles per hour or kilometers 1. Press any button on the console or begin ped- per hour.
- Page 16 All manuals and user guides at all-guides.com 5. Measure your heart rate if desired. 6. Turn on the fan if desired. If there are To turn on the fan at high speed, press the Cool- sheets of clear aire Fan button. To turn on the fan at low speed, Contacts plastic on the press the button a second time.
- Page 17 All manuals and user guides at all-guides.com HOW TO USE A PRESET WORKOUT arrow appears in the display, increase your Arrow 1. Press any button on the console or begin speed. When a down- pedaling to turn on the console. ward-pointing arrow appears, decrease your See step 1 on page 15.
- Page 18 All manuals and user guides at all-guides.com HOW TO USE THE SOUND SYSTEM Next, press the play button on your MP3 player or CD player. Adjust the volume of the speakers using the To play music or audio books through the consoleʼs volume control on your MP3 player or CD player.
-
Page 19: Maintenance And Troubleshooting
All manuals and user guides at all-guides.com MAINTENANCE AND TROUBLESHOOTING HOW TO ADJUST THE BELT Inspect and tighten all parts of the exercise cycle reg- ularly. Replace any worn parts immediately. If you can feel the pedals slip while you are pedaling, To clean the exercise cycle, use a damp cloth and even when the resistance is at the highest level, the mild soap. -
Page 20: Exercise Guidelines
All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning time. During the first few minutes of exercise, your this or any exercise program, consult your body uses carbohydrate calories for energy. -
Page 21: Part List
All manuals and user guides at all-guides.com PART LIST—Model No. WLEX32709.0 R0809A Key No. Qty. Description Key No. Qty. Description Frame Wheel Rear Stabilizer Stabilizer Cap Front Stabilizer Bumper Upright Right Pedal/Strap Console Left Pedal/Strap Seat Carriage M10 x 41mm Shoulder Screw Pulse Bar M10 x 80mm Patch Screw Backrest... -
Page 22: Exploded Drawing
All manuals and user guides at all-guides.com EXPLODED DRAWING A—Model No. WLEX32709.0 R0809A... - Page 23 All manuals and user guides at all-guides.com EXPLODED DRAWING B—Model No. WLEX32709.0 R0809A...
-
Page 24: Ordering Replacement Parts
All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
