Pine Dining Set 1+4
Assembly Instructions -
Dimensions - Table
Length - 118cm
Width - 75cm
Height - 73cm
Important –
Please read these instructions fully before starting assembly
Ｉｍｐｏｒｔａｎｔ – Ｐｌｅａｓｅ ｒｅａｄ ｔｈｅｓｅ ｉｎｓｔｒｕｃｔｉｏｎｓ ｆｕｌｌｙ ｂｅｆｏｒｅ ｓｔａｒｔｉｎｇ ａｓｓｅｍｂｌｙ
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Please keep for future reference
Please keep for future reference
Dimensions - Chairs(x4)
Width - 41.5cm
Depth - 41.5cm
Height - 85.4cm
600/0509
600/1371
Issue 1 - 9/12/09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos 600/0509
Summary of Contents for Argos 600/0509
- Page 1 Pine Dining Set 1+4 Assembly Instructions - 600/0509 Please keep for future reference Assembly Instructions - 600/1371 Please keep for future reference Dimensions - Table Dimensions - Chairs(x4) Length - 118cm Width - 41.5cm Width - 75cm Depth - 41.5cm Height - 73cm Height - 85.4cm...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below Leg x 4 (4 x 71.2cm) underside (118 x 75cm) Seat x 4 (41.5 x 40.5cm) Left side x 4 Right side x 4 Back rail x 4 (85.4 x 42.7cm) (85.4 x 42.7cm) (28.5 x 5cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fitting bolts Insert assembly bolt into leg . Screw bolts into assembly bolt Repeat with remaining legs Step 2 Attaching legs Attach four the legs using washer and nut . Tighten the bolts with spanner...
- Page 6 Assembly Instructions Step 3 Fitting dowels Insert wooden dowels into back , front rail and back rail Insert wooden dowels into the other side of back , front rail and back rail...
- Page 7 Assembly Instructions Step 4 Step 4 Attaching side Attach back front rail , back rail and cross rail left side , with screws using allen key Do not tighten the screws at this point in time. Attach back front rail , back rail , and cross rail right side...
- Page 8 Repeat with remaining chairs. Tighten all the screws for table and chairs. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
