Rectangular table assembly Instructions

How to assemble Rectangular table

Tools Required

Power Driver
Phillips Bit
Rectangular table

Step 1

1.1 Attach top plate to the leg, with two M8 flat head machine screws.
Tighten screws until snug plus 1/2 turn.
1.2 There are 2 ways to mount the plate to the leg :
A. Square-Out for end legs and all free standing tables.
B. Round-Out for intermediate/shared legs
HermanMiller
5mm Allen Wrench
A.
OR
B.

Parts Included

Plate
Caster w/ Brake
#10 Flat Head
#10 Pan Head
Tapping Screw
Tapping Screw
Work surface

Step 2

2.1 Insert caster stem into bottom of leg until fully seated.
Note: This step is for caster option only.
1BSSGX rev A
1
Caster Leg
Glide Leg
M8 Flat Head Screw
Ganging bracket
Stiffener
Stiffener End Cap
Assembly Instructions
