DURAFIT
DURAFIT
AGILE
AGILE
USER GUIDE
world-class
futuristic
in the
fitness
industry
CONTACT:
6379905512 /
6383151885
EMAIL:
contactus@durafit.in
WEBSITE:
https://www.durafit.in/
C A U T I O N
R E A D T H I S M A N U A L B E F O R E U S I N G Y O U R
E Q U I P M E N T
products

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGILE and is the answer not in the manual?

Questions and answers

Related Manuals for Durafit AGILE

Summary of Contents for Durafit AGILE

  • Page 1 DURAFIT DURAFIT AGILE AGILE USER GUIDE world-class futuristic products in the fitness industry CONTACT: 6379905512 / 6383151885 EMAIL: contactus@durafit.in WEBSITE: https://www.durafit.in/ C A U T I O N R E A D T H I S M A N U A L B E F O R E U S I N G Y O U R...

  • Page 2: Special Tips

    Special tips: Before installation and operation, please read this operation manual carefully. 2. It is important your treadmill receives regular maintenance to prolong its useful life. Failing to regularly maintain your treadmill may void your warranty. 3. Please save this manual for future reference. “Today I will do what others won’t, so tomorrow I can accomplish what others can’t.”...
  • Page 3 Table of Contents Security Notice and Brief Description Warnings Installation steps Technical Features Operation and Setup Pre-exercise advice Frequently Asked Maintenance Questions Certifications Company Passed ISO9001:2000 Quality System Certification Most of our products have been passed European Union CE.RoHS, Germany TUV.GS,SGS Certification,and they are approved qualified two consecutive years for the sampling inspection performed by National Athletic Sports Goods Inspection Center.
  • Page 4 Security notice and warnings Treadmill is suitable to be placed in the room so as to avoid dampness. It can’t be splashed by water and can’t prevent any foreign materials. Before exercising, please wear suitable sports clothes and sports shoes. Prohibit running on the machine with naked feet and prohibit stretching the whole body on it.
  • Page 5 Warnings: In order to reduce accidents or injuries to others, please observe the following rules: Before using the machine, please check whether the clothes are buttoned up or zipped up. Don’t wear clothes that easy to be hooked by treadmill. Don’t make the power line close to the hot objects.
  • Page 6 4.People who have circulation system troubles(heart disease, dysfunction of blood vessel, high blood pressure, etc) . 5.People who have troubles in breathing organs. 6.People who are using artificial pacemaker to implant medical electrical instruments into the body. 7.People who have malignancy. 8.People who suffer disturbance of blood circulation like thrombosis or serious dynamic fatty tumor, acute still fatty tumor etc., or all kinds of skin infections.
  • Page 7 May cause troubles or Poor health During exercising process, if you feel pains, like waist pain, leg &foot numbness, dizziness, heartbeat that are different from that at ordinary times or abnormal adjusting feeling, please stop using immediately and consult your doctor. Don't let children use this product and keep them away.
  • Page 8 It can’t be simultaneously used by two people or morethan two people. During use, notice that do not let people around get close to it. Otherwise, accidents or injuries may be caused by falling. People who can’t express their consciousness or can’t operate it are not allowed to use.

  • Page 9: Brief Description

    1. Brief Description Motorized treadmill can helps to complete your goal of keeping fit together with unique and elegant appearance. Easily read panel parameter. All makes it a hot home use fitness equipment. “If you want something you’ve never had, you must be willing to do something you’ve never done.”...

  • Page 10: Technical Features

    2. Technical Features Value Contents Time, Speed, Distance, Panel displays Calories, Pulse Rate Display Mode Running Area 1170*405 (mm) Motor 2 HP (4 HP) DC Machine Size(L*W*H) 1540*720*1290 (mm) Max. weight (Walking) 120 kg Max. weight (Running) 90 kg Inclination No Inclination Auto Lubrication, 100% Silicone Lubrication...
  • Page 11 Modes 4 SA Modes Input voltage 220 V 50HZ Frequency Input current ≤8A Temperature 4 0℃ ∽ 54 / 46 KG Gross Weight/ Net Weight Power Consumption 1.6 kW / hr 2 persons for 30 min with No. of persons usage interval of 25 “If you want something you’ve never had, you must be willing to do something you’ve never done.”...

  • Page 12: Installation Steps

    3. Installation Steps When installing, first simply fix all the screws, and then tighten up after the shelf has been installed. Step-1: Cut the white tie on the left and right sides with scissors as shown. Step-2:(For multi-function only) 1) Turn massage head and tight. 2)Turn the massage head as the photo shows, it will lock with U tube automatically, tight Screw clockwise.
  • Page 13 Step 3: Stand up and lock the column Raise the column in the direction shown, the column is automatically locked with the chassis, and the button is screwed clockwise, one on each side. Step 4: Rotate and lock the U-tube 1) Pull the left lock knob to the bottom and turn the knob counterclockwise.
  • Page 14 Step 5: Rotate and lock the watch Rotate the electronic watch in the direction shown, the electronic watch will automatically lock, turn the knob clockwise, one on each side. Step 6: Arrange upright cover Install the column sheath without locking screws. “To give anything less than your best is to sacrifice the gift.”...

  • Page 15: Operation And Setup

    Step 7: Place the Safety Tether Key onto the Computer Bracket. 4. Operation and Setup “To give anything less than your best is to sacrifice the gift.”...
  • Page 16 DISPLAY WINDOW 1.“CALORIES” window: Display the calorie consumption value. When the calorie consumption value is displayed, the positive count will be from 000-999 kcal. After overflow, it will be cleared and continue to run. 2."HEART RATE" window: Displays the heartbeat value of the customer. When the user holds the heartbeat sensor handle in both hands, the system can automatically detect the heartbeat frequency and display it in this window.
  • Page 17 2. Healthy walk mode: standby state, used to adjust the exit and entry of the set healthy walk mode, enter the healthy walk mode “SPEED” window displays “PC”, and “TIME” window shows time countdown ; exit the healthy small walking mode “SPEED”...
  • Page 18 PROGRAM There are 3 different programs for this system. 1.Free mode: In the standby state, press the “Start” button directly, the treadmill will start running after 3 seconds delay and start running at 0.8 km/h; other windows will start counting from 0, press “Speed+”, “Speed- ” key to adjust the speed;...
  • Page 19 5. Pre- exercise advice Stretching exercise: Whatever your running speed is, you’d better do stretching exercise first. Warm muscles are easier to stretch, so walk for 5 to 10 minutes to warn up. Next, stop to do stretching exercise for five times according to the following methods, 10 seconds or more for each leg, and do again after exercising.

  • Page 20: Exercise Instruction

    Exercise Instruction Warm-up: Take warm-up exercise for 5 to 10 minutes before using this machine each time. Breathing: When exercising, you can’t hold your breath, usually inhale with nose when intending to release actions, and exhale with mouth. Inhaling should be coordinated with exhaling.

  • Page 21: Maintenance

    6. Maintenance Lubricating The running belt must be lubricated with specially configured methyl silicone oil after used for a period of time. 1. Advice: When use time a week is less than 3 hours, it should be lubricated once in five months.
  • Page 22 2. Lubricating methods For the methods to examine whether it is needed lubricant, you only need catch up the running belt and touch the central part of the back of the belt with hand as nearly as possibly. If the belt is with silicon resin (a bit sense of dampness) inside, this means no lubricant is needed;...
  • Page 23 If the deviation phenomenon is caused by the uneven force of the user’s feet, no-load rotation for a few minutes can make it normal. For deviation phenomenon that can’t return to normal automatically, adjust step by step by using 6MM inner hexagon spanner with the machine and with quarter-circle as the unit.

  • Page 24: Frequently Asked Questions

    7. Frequently Asked Questions Code Solution Main reason Check the connection wire between computer and control board was well The wire from connected. computer to bottom 2. Make sure the IC on the control board was control board didn’t well inserted. If not re-insert. connected well 3.
  • Page 25 TO BUILD AN EXTENSIVE PRODUCT PORTFOLIO, PROVIDE THE BEST CUSTOMER EXPERIENCE Make your body clock Make your body clock Make your body clock work for you! work for you! work for you! Scan the QR code...
