- Page 1 Commercial Treadmill Operating Instructions Manual Special tips: Before installation and operation, please read this operation manual carefully. Please save this manual for future reference.
-
Page 2: Table Of Contents
Table of Contents 1 Brief Description…………………………………………………………………1 2 Main Technical Features…………………………………………………………1 3 Tips for safety…………………………………………………………………………2-3 4 Installation………………………………………………………………………………3 5 Use and Operation……………………………………………….………………… 3-7 6 Maintenance…………………………………………………………………………..7-9 7 Guides for malfunction…………………………………………………………… 9-10 8 Warranty…………………………………………………………………………………10-11 9 Error and self-inspection…………………………………………………………. 11 10 Installation Sketch………………………………………………………………….12-14... -
Page 3: Brief Description
1. Brief Description motorized treadmill (diagram 1) can help complete your goal of keeping fit together with unique and elegant appearance. Easily read panel parameter. Easily operated folding system realizes space-saving. Auto speed range 1-22km/h and auto incline range0-18%. All makes it a hot Commercial use fitness equipment. -
Page 4: Tips For Safety
3. Tips for Safety 3.1 Insert the power plug into the socket directly. Current load should be less than 15A. 3.2 The constant max weight is less than 180kgs. 3.3 Place your treadmill on the clean floor，not on the thick carpet, otherwise it will not convenient for ventilation. -
Page 5: Installation
3.16 when in running,we have to keep there is enough free space behind the treadmill ,usually as the rule,it should be length(2m) and the width should be the same as treadmill 3.17 please kindly add 20ml professional oil per time after 3days’ work or 20 hours’ running time. - Page 6 5.1 Panel Keys and Function （3）vol+ （1）Next （4）vol - （2）Prev. （24）LCD window （5）Time window （23）Pluse window （6）Distance window （22）Calorle window （7） Speed window （21）Incline window （8）incline shortcut key （20）speed shortcut key （19） music （9） body fat （10） （18） incline-up speed-down （11）...
- Page 7 （9） “body fat ” Press once, it will show “BODYFAT” in window, and then press “MODE” button, “SEX1”, which indicated “man”, will show in the window. Then “man” (1) or “woman” (2) can be selected by “speed up” and “speed down” buttons. Press “mode”...
- Page 8 （10） “incline-up” Press this key one by one or Press it continuously, you can choose the incline you need, except for the alarm condition. （11） “incline-down” Press this key one by one or Press it continuously, you can choose the incline you need, except for the alarm condition.
-
Page 9: Maintenance
It shows calorie. (range:1 -999cal） （23） “Pluse window” It shows the pulse. (range:0-250） （24） “LCD window” It shows 400mm Racetrack 5.2 Unload operating 1. Insert power plug into the socket with earth wire, turn the switch to “1” position which is on the frame 2. - Page 10 c) Turn the speed to be around 3km/h, step on the running belt by pressure and try your best to make the running belt stop. If running belt stops, but front roll still runs, under this condition, it means the running belt needs to be adjusted. 6.2 The adjustment steps for poly V-belt Cut off power firstly and take down the cover of protection.
-
Page 11: Guides For Malfunction
The treadmill is equipped with lubricated running board, which needs constant maintenance. The friction between running board and running belt has a great effect on the treadmills’ e life. So please lubricate your machine termly. The steps are as follows: a) Cut off the power b) Wipe out the dust between running board and running belt with a clean cloth. -
Page 12: Warranty
unconnected Turn on the meter and reconnect Heart rate can’t be displayed The pole of heart rate sensor Wet the pole with water or liquor for is not wet enough hard contact lenses Disturbed Stay away from electromagnetism electromagnetism Incline doesn’t work The motor wire is not well Open the motor cover and reconnect connected... - Page 13 9.2 Self-inspection No need to self-inspect unless special situation. If necessary, please do it under the instruction of professional technical people or sales because of the high voltage. a，open the red power switch and make sure again the safety key is not released.(if released, please press down the key) b，Press the “start”...
-
Page 14: Installation Sketch
- 12 -... - Page 15 - 13 -...
-
Page 16: Part List
Proofreading has been carefully done to the manual, if there are printing mistakes, please kindly understand. If pictures and the real product doesn’t match, please take the product as the final and correct one. If any improvement on function and specification, please kindly understand if you are not informed. - Page 17 Name Name Name Meter Frame foot pad Meter Frame Left End cap Front Roller Right End cap Right knighthead Deck Left knighthead Running Belt Incline Motor Real roller Driver belt Side Rail Motor Side Rail Foot Pad Frame Tube Handrail foam Frame inverter Wheel...
