Special tips:
1.
Before installation and operation, please read this operation manual carefully.
2.
Please save this manual for future reference.
1 Brief Description...........................................................................2
DFISA001 Motorized Treadmill
Operating Instructions Manual
Table of Contents
Advertisement
Table of Contents
Related Manuals for Durafit DFISA001
Summary of Contents for Durafit DFISA001
- Page 1 DFISA001 Motorized Treadmill Operating Instructions Manual Special tips: Before installation and operation, please read this operation manual carefully. Please save this manual for future reference. Table of Contents 1 Brief Description…………………………………………………………………2...
-
Page 2: Table Of Contents
5 Use and Operation……………………………………………………………… 4-6 6 Maintenance…………………………………………………………………… 6-8 7 Guides for malfunction………………………………………………………… 8-9 8 Warranty………………………………………………………………………… 9 9 Error and self-inspection………………………………………………………… 9-10 10 Installation Sketch……………………………………………………………11-12 1. Brief Description DFISA001 motorized treadmill (diagram 1) can help complete your goal of keeping fit - 1 -... -
Page 3: Main Technical Features
Pillar accessories Footplate Running belt adjustor Running belt Power switch Diagram 1: DFISA001 Motorized Treadmill 2. Main Technical Features Main use: Body and beauty building This treadmill is for home use Panel displays speed, time, distance, heart rate, calorie etc. - Page 4 The constant running time is less than 2 hours, max weight is less than 120kgs. Place your treadmill on the clean floor，not on the thick carpet, otherwise it will not convenient for ventilation. Also please don’t put the treadmill in the moist place or outdoors; If there is something wrong with the electrical wire, please replace it with the electrical wire provided by our company.
-
Page 5: Installation
thorax ache or other symptoms. 3.15 Please drink adequate water after taking exercises on our treadmill for more than 20 minutes. 4. Installation: See “Installation sketch” 5. Use and Operation 5.1 Panel Keys and Function （1）MP3 （2）Prog （3）incline shortcut key （4）speed shortcut key （5）incline-up （6）... - Page 6 （2）“PROG”(could be pressed continuously to your expected mode) Press the “PROG” key once again to enter “48 direct selected programs” there are 48 programs, “P1-P48” the first 24 programs without incline, the last 24 programs including incline. So please choose carefully. （3）“incline short cut key”...
-
Page 7: Maintenance
5.3 Meter operating instruction 5.3.1 1. Insert power plug into the socket with earth wire, turn the switch to “1” position which is on the frame. Place the safe key to the appointed position. After a few seconds, panel will show that the machine is ready. - Page 8 Cut off power firstly and take down the cover of protection. a) Loosen the four screws for the motor, adjust them in a circuit clockwise, then screw down the loose screws. b) Keep the power on, and adjust the poly V-belt is loose or not following the point 3.1 above, if yes, please repeat the action same to point a) above.
-
Page 9: Guides For Malfunction
d) While adding lubrication oil, please keep your clothes away from the machine for avoiding the injury. 6.6 Cleaning a) Please power off and pull the plug cap out before cleaning. b) Wipe out the dust stuck on the surface and running board frequently. c) Please clean the surface of frame and running belt with a soft cloth dipped with suds, don’t use things like eradicator and naphtha.(After cleaning, please dry it for use) d) Please take the protecting cover off every two month, use vacuum dust-collector to suck the... -
Page 10: Warranty
displayed Running belt slips Running belt is not tight Please read point 3.3 Adjustment enough steps for tightening running belt for reference Running belt is deflected running belt Please read point 3.4 The steps unadjusted. adjusting deflected running belt for reference 7.2 If you still can’t solve the problems after taking the solutions above, we hope that you can contact our dealer or company as soon as possible. - Page 11 9.2 Self-inspection No need to self-inspect unless special situation. If necessary, please do it under the instruction of professional technical people or sales because of the high voltage. a，open the red power switch, pull out the safe key b，Press the “start” and ”speed +” key at the same time and keep it,meanwhile,use another hand to put on the safe key ,then release the button.of “start”and “speed+”...
-
Page 12: Installation Sketch
- 11 -... - Page 13 Proofreading has been carefully done to the manual, if there are printing mistakes, please kindly - 12 -...
- Page 14 understand. If pictures and the real product doesn’t match, please take the product as the final and correct one. If any improvement on function and specification, please kindly understand if you are not informed. - 13 -...
