INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
18" High Output Brass Rotatable LED Hardscape Light
®
VHS-6719-25-BBZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2021, VOLT
reserved. customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Lighting, Lutz FL USA 33549 • All rights
®
- 1 -
Advertisement
Related Manuals for Volt VHS-6719-25-BBZ
Summary of Contents for Volt VHS-6719-25-BBZ
- Page 1 VHS-6719-25-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights ® reserved. customersupport@voltlighting.com • 813.978.3700 - 1 -...
-
Page 2: Package Contents
VOLT 18” High Output Brass Rotatable LED Hardscape Light ® VHS-6719-25-BBZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Optional: Install Glare Guard Before Installation Screw If you choose, you can attach the glare guard first before mounting Washer the fixture. Use the screws and washers to secure the glare guard onto the fixture. Tighten with a screwdriver. Install Luminaire in Brick or Masonry Wall Install Mounting Plate Determine the desired location for Brick or...
-
Page 4: Wire Connection
INSTALLATION INSTRUCTIONS VOLT 18” High Output Brass Rotatable LED Hardscape Light ® VHS-6719-25-BBZ Wire Connection Luminaire Wires Wire Connectors Main Low Voltage Supply Cable Strip both leads from the luminaire pigtail. Using two UL listed wire connectors (sold separately), connect the leads from the luminaire to the main supply cable leads. - Page 5 Install Luminaire in Railing, Deck Over-hang or Stair Determine Luminaire Location Mark Railing, Deck over-hang or Stair Railing, Deck over-hang or Stair Wireway Slot Mark Luminaire Luminaire Wireway Self-tapping Self-tapping Slot Screw Screw Install from Bottom Install from Side Determine the desired location for the luminaire. Place the luminaire to the mounting surface and mark two points on the mounting surface where the holes are on the ends of the luminaire.
- Page 6 INSTALLATION INSTRUCTIONS VOLT 18” High Output Brass Rotatable LED Hardscape Light ® VHS-6719-25-BBZ Install Luminaire Railing, Deck Mark over-hang or Stair Railing, Deck Wall Anchor over-hang or Stair Wireway Hole Wall Anchor Glare Guard Mark Wireway Luminaire Self-tapping Luminaire Glare...
-
Page 7: Wire Connections
Wire Connections Luminaire Wires Wire Connectors Main Low Voltage Supply Cable Strip both leads from the luminaire pigtail. Using two UL listed wire connectors (sold separately), connect the leads from the luminaire to the main supply cable leads. * We recommend ace heat shrink style connectors for hardscape connections. - Page 8 INSTALLATION INSTRUCTIONS VOLT 18” High Output Brass Rotatable LED Hardscape Light ® VHS-6719-25-BBZ Install Riser Pass the supply wire from the luminaire through the center Luminaire hole on the Y bracket and the riser. Then thread the riser onto the Y bracket and hand Supply Wire tighten until snug.
- Page 9 Intsall Riser to Stake Clear away area in the ground at wireway slot on the top of the stake. Pass the fixture supply wire through the center hole of the stake and lay it into the wireway slots. Thread the Riser riser onto the stake.
- Page 10 INSTALLATION INSTRUCTIONS VOLT 18” High Output Brass Rotatable LED Hardscape Light ® VHS-6719-25-BBZ Adjust Lamp Direction Set Screw Allen Wrench Set Screw Lamp Using an Allen wrench, loosen the set screws on the ends of the lamp and then rotate the lamp to the desired direction. Always tighten the set screws after adjustments.
- Page 11 customersupport@voltlighting.com • 813.978.3700 - 11 -...
- Page 12 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights ®...
