Package Contents

Package Contents
Check the contents of each kit and other parts to ensure that all components are present. Keep the kit hardware in
the labeled bag as they will be used in different assembly steps.
See "Parts List" on page 23 for a complete list of replacement part numbers.
PRIMARY ASSEMBLY COMPONENTS
#1
#6
1
Primary Sub-Assembly (x1)
4
Rim (x1)
7
Knuckle Shroud (x1)
31 Cover, Extension Arm (x1)
KIT 1 – 209220
#8
8
Bolt, Hex, 3/8-16 x .625" (x4)
204961 hex head bolt 3/8-16 x 5/8
#2
#28
#7
2
Extension Arm (x1)
5
Rim Cover, Orange (x1)
9
Rim Bracket (x1)
#3
#4
#5
3
6
28 Plug, Base (x2)
4
#9
#31
Backboard Assembly (x1)
Front Cover (x1)
