DTO- CD
DESKTOP ORGANIZERS
I M P O R TA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
1207
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DTO- CD and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironwood DTO- CD

  • Page 1 DTO- CD DESKTOP ORGANIZERS I M P O R TA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of...
  • Page 2: Parts Diagram

    PARTS DIAGRAM 05761601 1 ea. Fixed Shelf 05761721 1 ea. Back 05761752 1 ea. Left Side 05761742 1 ea. Right Side 05761742 1 ea. Adjustable Shelf 00000000 3 ea. Left Divider 05761744 1 ea. Right Divider 05761744 1 ea. HARDWARE Minifix Cam 909810 18 ea.
  • Page 3 Using the Rafix System: Insert the Rafix Cams into the appropriate holes. The flat edge of the cam should be facing the edge Flat of the panel. edges must be Slide Rafix Cams of the panel to be aligned attached onto the corresponding posts. When screwing post into hole, Do Not over tighten.
  • Page 4 Insert 7 Minifix Cams (H1) into Back Panel (D) with arrow facing outward, screw in 3 Minifix Bolts (H2) into back as shown. Insert 7 Minifix Cams into Fixed Shelf (G). Insert 6 Wood Dowels (H3) and 7 Minifix Bolts (H2) into Top (C) as shown.
  • Page 5 Place Back (D) as shown. Position Fixed Shelf (G) onto Back. Turn Minifix Cams (H1) clockwise to secure. Position right side (B) onto back (D) and Fixed Shelf (G) as shown. Turn Minifix Cams (H1) clockwise to secure. Position left side (A) onto back (D) and Fixed Shelf (G) as shown. Turn Minifix Cams (H1) clockwise to secure.
  • Page 6 Select side that you would like the CD Rack on - right side or left side of unit. Use 4 flathead screws (H5) to install outside CD rack (H7) or (H8) as shown in the diagram. Using 4 Flathead Screws (H5) install the remaining CD Rack LEFT RIGHT...
  • Page 7 # 11 On opposite end of CD Rack RIGHT CONFIGURATION installation screw in 3 Rafix bolts (H6) in holes furthest out from side as shown. Slide Divider Panel (E or F) onto Rafix bolts and rotate Rafix Housing 1/2 turn clockwise LEFT CONFIGURATION to secure.
  • Page 8 # 14 Set the 3 Adjustable shelves (J) onto Shelf Pins (H9). RIGHT CONFIGURATION LEFT CONFIGURATION Press the 3 plastic Label Holder Moldings (H11) onto the front of each of the Adjustable Shelves (J). RIGHT CONFIGURATION LEFT CONFIGURATION # 15 Slide the 5 Metal Shelf Dividers (H10) onto the upper Shelf (G) positioning as desired.
