Ironwood DTS Quick Start Manual

Deluxe typing stand

Advertisement

Quick Links

DTS
DELUXE
TYPING STAND
I M P O R TA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
0307
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DTS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ironwood DTS

  • Page 1 DELUXE TYPING STAND I M P O R TA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of Before you begin assembly: the missing part(s) to: PARTS, Box 1420, Missoula, MT 59806 or call:...
  • Page 2: Parts Diagram

    PARTS DIAGRAM Left Side Panel 05850141 1 ea. Right Side 05850341 1 ea. Worksurface 05850101 1 ea. Paper Rack Top 05850118 1 ea. Paper Rack Side 05850116 2 ea. Back 05850152 1 ea. Paper Rack Paper Shelf 05850119 1 ea. H1053 4 ea.
  • Page 3 HARDWARE 195000 8 ea. Wood Dowel Minifix Bolt 909834 8 ea. Caster Bracket 402303 4 ea. Minifix Cam 909810 8 ea. 402290 4 ea. Stem Caster Caster Socket 402301 4 ea. Washer Head 920201 2 ea. Screw 950100 9 ea. Confirmat Screw Using the Minifix System: Insert the Minifix Cams into the...
  • Page 4 Screw four Minifix Bolts (H1) into the pre-drilled holes of the Worksurface (C) where indicated. Insert four Wood Dowels (H2) into Worksurface (C) where indicated. Screw two Minifix Bolts (H1) into pre-drilled holes of each Side (A and B) where indicated. Insert two Wood Dowels (H2) into pre-drilled holes of each Side (A and B)
  • Page 5 Insert four Minifix Cams (H3) into the Back (D) as shown. Position the Back onto the Left Side (A) as shown. NOTE: Note the hole orientation on Back (D). Rotate Minifix Cams clockwise to lock in place. Position the Right Side (B) onto the Back (D) as shown.
  • Page 6 Use four Confirmat Screws (H7) to attach the other Paper Rack Side (E) as shown. Select either a left or right-hand Paper Rack placement. Attach Paper Rack unit to the underside of the Worksurface (C) using two Washerhead Screws (H8) in the pre-drilled holes as shown.
  • Page 7 # 11 Turn each of the (4) plastic paper Trays Insert eight Shelf Pins into the pre-drilled holes upside-down and remove the four plastic in both Paper Rack sides as shown. pins located on the back edge of the tray. BOTTOM VIEW OF TRAY Assembly of the Deluxe Typing Stand is now complete.
