BY
LIBRARY SHELVING UNIT
LS42SB LS48SB
LS60SB LS72SB
LS84SB
SINGLE
BASE UNIT
I M P O R TA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
0709
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
Advertisement
Table of Contents
Related Manuals for Ironwood Glacier LS42SB
Summary of Contents for Ironwood Glacier LS42SB
- Page 1 LIBRARY SHELVING UNIT LS42SB LS48SB LS60SB LS72SB LS84SB SINGLE BASE UNIT I M P O R TA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person.
- Page 2 PARTS DIAGRAM 01200141 1 ea. 01200141 1 ea. Right Side - LS42SB Left Side - LS42SB 01200241 1 ea. 01200241 1 ea. Right Side - LS48SB Left Side - LS48SB Right Side - LS60SB 01200341 1 ea. Left Side - LS60SB 01200341 1 ea.
- Page 3 If you have purchased an Adder unit to be assembled in conjunction with this Base unit, it is important to read all the way through the Adder instructions (enclosed in the Adder carton) before beginning. It will be necessary to substitute a Divider (J) for a Right Side (B) during assembly. If you have purchased the Back option or the Toe Space option to be assembled in conjunction with this Base unit, it is important to read through the Back option...
- Page 4 USING THE TAB-V SYSTEM: Using a plastic mallet, tap in the plastic housings with the flat edge facing outwards until flush with the surface. IMPORTANT! The flat edge of the plastic FLAT housing must be EDGE aligned with the shelf edge.
- Page 5 Install four Plastic Housings (H1) into each shelf. Attach a Book Stop (H2) to each Fixed/Adjustable Shelf (E) using five Panhead Screws (H3) in the pre-drilled holes. Install four Plastic Housings (H1) into the Top Panel (C) as shown. Place both Sides (A & B) on a clean, carpeted surface as shown. Install Metal Flanges (H4) using Varianta Screws (H5) in each Side Panel into the selected pre-drilled holes as indicated.
- Page 6 Attach a Metal Frame (H6) or Back Panel (D). METAL FRAME 3/4" BACK Use five #8 x 5/8" Follow the instructions included Panhead Screws (H3). with the Back Panel. NOTE: If you are installing an Adder, follow the instructions for an Adder unit at this time. With the assistance of another person, stand the assembly upright and install the other side panel (B).
- Page 7 NOTE: If you are installing the Toe Space option, it is recommended to install the Toe Space at this time. Follow the directions included with the Toe Space option. Attach the Top Panel (C) and the Fixed Shelf (E) using the Tab-V System. Turn the Cams 1/2 turn to tighten.
- Page 8 Your Glacier Library Shelving Unit is now assembled and ready for use.
